Overview
Place of Origin: |
USA |
Brand Name: |
GE |
Model Number: |
VMIPCI-5565-110000 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Description |
Specification |
|
Model |
VMIPCI-5565-110000 |
|
Part name |
Control Pulse Module |
|
Dimensions |
2.2x18.8x12.6cm |
|
Weight |
0.12kg |
|
Power requirements |
+5 V DC @ 1.7 A; +12 V DC @ 0.3 A; -12 V DC @ 0.1 A |
|
Operating temperature |
0°C ~ +55°C |
|
Storage temperature |
-40°C ~ +85°C |
|
Bus interface |
PCI bus |
|
VXI/VME interface |
VME64x with 2eSST capability |
|
Data width |
32-bit |
|
DMA channels |
4 |
|
Transfer rate |
Up to 132 MB/s |
|
Interrupts |
4 independent interrupt vectors |
|
Onboard memory |
32 MB |
Description
GE VMIPCI-5565-110000 is a Control Pulse Module. It is often used to generate and manage precise pulses that are crucial for the control of various industrial equipment and processes. It acts as an interface between a digital control signal from a computer or controller and a physical device that requires pulse-based control.
Applications
Aerospace Simulations: Synchronizes flight simulator nodes for real-time position and attitude control.
Semiconductor Plants: Provides microsecond synchronization for multi-axis lithography with nanometer precision.
Power Testing Labs: Supports RTDS systems for synchronized high-frequency waveform acquisition and computation.
Automotive Test Facilities: Enables closed-loop torque and speed control for high-speed test benches.
MRI Manufacturing Plants: Enables real-time data exchange between imaging systems and gradient drivers.
Troubleshooting and Maintenance Recommendations
Bus Audit: Check PCI/VME gold fingers and ensure modules are firmly locked in vibration environments.
Thermal Maintenance: Maintain chassis airflow and clean dust filters regularly.
Power Check: Monitor +5V and +12V stability to avoid sync or data errors.
Storage Test: Run self-diagnostics to verify onboard read/write consistency and data reliability.
FAQ
Q: How efficient is the VMIPCI-5565-110000 in large-scale real-time data interaction?
A: It supports up to 132 MB/s transfer rate with 32-bit width for high-performance real-time tasks.
Q: How many interrupt requests does the VMIPCI-5565-110000 support?
A: It provides four independent interrupt vectors for flexible multi-task scheduling.
Q: How does the VMIPCI-5565-110000 perform in memory caching?
A: It integrates 32 MB high-speed onboard memory for buffering large control data streams.
Q: What are the power requirements of the VMIPCI-5565-110000?
A: It uses +5V DC at 1.7A with additional ±12V supply support for embedded systems.
Q: Is the VMIPCI-5565-110000 reliable in wide temperature environments?
A: Yes. It operates from 0°C to 55°C and withstands storage from -40°C to +85°C.
