Overview
Place of Origin: |
USA |
Brand Name: |
RELIANCE |
Model Number: |
VCIB-16A |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Description |
Specification |
|
Model |
VCIB-16A |
|
Part name |
AC Servo Drive |
|
Dimensions |
23.5x25.5x44.2cm |
|
Weight |
14.5kg |
|
Operating voltage |
230 VAC ±10% |
|
Output current |
16 A |
|
Control protocol |
EtherCAT, CANopen |
|
Motor compatibility |
Up to 2.5 kW |
|
Communication interface |
USB, Ethernet |
|
Protection class |
IP20 |
|
Operating temperature |
-10°C to +50°C |
Description
The VCIB-16A is an advanced AC servo drive designed for precision control in industrial applications. It offers high performance, reliability, and efficiency, making it ideal for demanding environments where accuracy and stability are paramount.
Applications
Precision Machine Tools: Drives CNC feed axes for improved surface finish via high dynamic response.
Automated Assembly Plants: Powers robots and stackers for precise end-effector positioning.
Packaging Plants: Drives high-speed sealing and labeling with synchronized bus control.
Lithium Battery Plants: Controls coating and winding tension with precise torque regulation.
Logistics Facilities: Powers shuttle and sorting systems for continuous high-frequency operation.
Troubleshooting and Maintenance Recommendations
Heat Dissipation: Clean ventilation holes regularly to prevent overheating and derating.
Bus Self-Test: Check EtherCAT/CANopen shielding and port indicators if errors occur.
Power Monitoring: Ensure AC input stays within ±10% to avoid DC bus alarms.
Cable Maintenance: Tighten output terminals to prevent vibration-induced poor contact and arcing.
FAQ
Q: What mainstream industrial control protocols does the VCIB-16A servo drive support?
A: It natively supports EtherCAT and CANopen, compatible with most motion control systems.
Q: What motor power range can the VCIB-16A drive support?
A: It is designed for servo motors up to 2.5kW, providing sufficient power margin.
Q: What are the power supply requirements for the VCIB-16A?
A: It operates at 230VAC with ±10% tolerance for standard industrial environments.
Q: What is the rated output current of the VCIB-16A and is it suitable for heavy loads?
A: It provides 16A output current with efficient current loop control for strong acceleration performance.
Q: Is the VCIB-16A suitable for humid or high-temperature environments?
A: It operates from -10°C to +50°C with IP20 protection, suitable for standard industrial cabinet use.
