Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
TC-FTEB01 51309512-125 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
TC-FTEB01 51309512-125 |
|
Product Type |
Ethernet Module |
|
Dimensions |
3.4 × 14 × 14.5 cm |
|
Weight |
0.28 kg |
|
Supply Voltage |
24 VDC |
|
Communication Protocol |
Modbus RTU |
|
Output Signal |
4–20 mA |
|
Output Impedance |
100 Ω |
|
Resolution |
12 bits |
|
Accuracy |
±0.1% |
|
Repeatability |
±0.02% |
|
Mounting Type |
DIN rail mounting |
|
Protection Rating |
IP65 (dust tight, protected against water jets) |
|
Operating Temperature Range |
-40°C to 75°C |
Description
Honeywell's TC-FTEB01 51309512-125 is an Ethernet module for industrial control racks. This module transmits real-time machine operation status, equipment switching, and instrument readings from inside the rack to the central control room computer, while simultaneously transmitting computer commands to the rack, keeping the production site synchronized with the back-end monitoring system. It is widely used in automated operation sites such as oil, chemical, and power plants.
Applications
Chemical Plants: Connect control systems for remote process monitoring.
Refineries: Transmit real-time data from distillation and cracking units.
Power Plants: Integrate boiler and turbine data into plant networks.
Pharmaceutical Plants: Ensure stable transfer of cleanroom and batch data.
Paper Mills: Connect paper machine and pulping automation networks.
Features
Fast Ethernet Protocols: Enables high-speed data transmission for real-time control and monitoring.
Reliable communication: Facilitates robust data exchange between control systems and field devices.
Compact Design: Small footprint for easy integration into Honeywell chassis.
Industrial Grade: Built for demanding automation environments with long-term reliability.
Installation
To insert the FTE Bridge module into the chassis
1. Align the module's circuit board with the top and bottom chassis guides for the planned slot location. Typically, slot 0 is reserved for the communication module. (Remember that slot numbering is zero-based and the left most slot is number "0".)
2. Slide the module into the chassis, until the module's locking tabs "click" into position. The module is fully installed when it is flush with the power supply or other installed modules.
3. Repeat Steps 1 and 2 to install other modules, as required.
4. Go to the next Section Attaching FTE cables.
FAQ
Q: What is the supply voltage of TC-FTEB01 51309512-125?
A: Its supply voltage is 24 VDC.
Q: What communication protocol does TC-FTEB01 51309512-125 use?
A: It uses the Modbus RTU communication protocol.
Q: What output signal can TC-FTEB01 51309512-125 provide?
A: Its output signal is 4–20 mA.
Q: What is the output impedance of TC-FTEB01 51309512-125?
A: Its output impedance is 100 Ω.
Q: What is the output resolution of TC-FTEB01 51309512-125?
A: Its resolution is 12 bits.
