Overview
Place of Origin: |
USA |
Brand Name: |
ICS TRIPLEX |
Model Number: |
T9191 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
T9191 |
|
Product Type |
Blanking Cover |
|
Application |
For I/O positions with no TA fitted |
|
Material |
ABS plastic |
|
Color |
Gray |
|
Dimensions (H x W x D) |
85 x 25 x 15 mm (3.35 x 0.98 x 0.59 in) |
|
Operating Temperature Range |
-20 °C to +70 °C (-4 °F to +158 °F) |
|
Protection Class |
IP20 |
|
Flammability Rating |
UL 94 V-0 |
|
Installation Type |
Module slot blanking cover |
Description
The T9191 is a I/O slot blanking cover manufactured under the ICS Triplex Trusted series. This cover is used to seal and protect vacant I/O slots on the chassis or base unit where no Termination Assembly (TA) is currently fitted.
Applications
Petroleum Refineries: Seals empty cabinet slots to block gas and corrosion ingress.
Chemical Plants: Covers spare slots to prevent chemical vapor damage.
Thermal Power Plants: Protects unused areas from dust and fly ash intrusion.
Nuclear Power Plants: Seals redundant slots to maintain airflow and shielding.
Troubleshooting
Blind plate clip loose or cannot lock—check ABS claws for deformation or damage; ensure no obstruction in I/O slot edge.
Adjacent module overheating alarm—ensure all unused slots are fitted; missing plates disrupt cabinet airflow and cooling.
Blind plate discoloration or embrittlement—replace during overhaul if exposed to overheating or chemical corrosion.
FAQ
Q: Where is T9191 blind plate used in ICS Triplex systems?
A: Used to cover empty I/O slots where no termination assembly (TA) is installed.
Q: What are the dimensions of T9191 blind plate?
A: 85 mm (3.35 in) height, 25 mm (0.98 in) width, 15 mm (0.59 in) depth.
Q: What flame rating does T9191 meet?
A: Made of ABS plastic, compliant with UL 94 V-0 flame retardant standard.
Q: What is the protection rating of T9191?
A: IP20 protection, preventing finger or >12 mm object intrusion.
Q: What is the operating temperature range of T9191?
A: -20°C to +70°C (-4°F to 158°F).
