Overview
Place of Origin: |
USA |
Brand Name: |
ICS TRIPLEX |
Model Number: |
T8290C |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Part Number |
T8290C |
|
Part Name |
Output Power Distribution Unit |
|
Rated Voltage Range |
22 to 120 Vdc |
|
Maximum Supply Current |
60 A |
|
Module Capacity |
Supports up to 3 Trusted Sourcing Output Modules (e.g., T8451, T8471 digital output modules) |
|
Operating Temperature |
0°C to +60°C |
|
Mounting Method |
Direct DIN rail mounting (TS32 or TS35) |
|
Certification |
IEC 60664-1 Overvoltage Category II; Pollution Degree 2 industrial environment |
Description
T8290C is an industrial-grade Output Power Distribution Unit designed for high-capacity power delivery in safety-critical control systems. It provides reliable distribution of DC power to field-side output modules, ensuring stable operation of large-scale automation and safety instrumented systems.
Applications
Petrochemical Refineries: SIS high-current distribution for solenoid valve control.
Thermal Power Plants: DC power for turbine trip and boiler relays.
Coal Gasification Plants: High-voltage DC for long-distance valve operation.
Offshore Platforms: Safe power distribution with insulation protection.
Automotive Manufacturing: High-density power for pneumatic valve systems.
Features
Multi-protocol support: Supports industrial protocols like Modbus and Profibus for cross-system compatibility.
High reliability: ICS TRIPLEX design ensures safety-critical performance and durability.
Easy maintenance: Standard interfaces simplify installation, configuration, and servicing.
Fault tolerance: HIFT and TMR architecture ensure continuous operation during component failure.
FAQ
Q: Can T8290C support 110Vdc distribution within its 60A rating?
A: Yes. It supports a wide 22–120Vdc range, fully compatible with 110Vdc systems.
Q: Can T8290C operate with only one T8451 module installed?
A: Yes. It supports flexible use from 1 up to 3 modules depending on demand.
Q: Does T8290C require a special base or DIN rail mounting?
A: No. It installs directly on TS32 or TS35 standard DIN rails.
Q: Can T8290C operate below 0°C in outdoor cabinets?
A: No. It is rated for 0°C to +60°C; heating is recommended in cold environments.
Q: What does Pollution Degree 2 mean for T8290C in industrial use?
A: It is suitable for normal industrial environments with non-conductive contamination.
