6DL3100-8AC02 AddFEM PoCo Position-Control Module
Official Siemens identification and technical data for 6DL3100-8AC02, prepared for accurate replacement matching and quotation.
At a Glance
| Article Number | 6DL3100-8AC02 |
|---|---|
| Manufacturer | Siemens |
| Platform | SIMATIC PCS 7 |
| Product Type | AddFEM PoCo Position-Control Module |
| Official Configuration | Position-control version for fast closed-loop control with PCS 7 driver integration |
Exact Identification
Match the complete Siemens article number 6DL3100-8AC02 and the photographed hardware revision.
Interfaces
Redundant PROFIBUS DP slave
Configuration Check
Confirm Position-control version for fast closed-loop control with PCS 7 driver integration before replacement.
Product Overview
6DL3100-8AC02 is officially identified by Siemens as SIMATIC PCS 7 AddFEM PoCo Position-Control Module. Position-control version for fast closed-loop control with PCS 7 driver integration.
The complete article number 6DL3100-8AC02 should be matched against the installed hardware, nameplate and official system documentation. Similar revisions can differ in memory, interfaces, operating system or configuration.
Key Functions
Model-Specific Configuration
6DL3100-8AC02: Position-control version for fast closed-loop control with PCS 7 driver integration.
System Interface
6DL3100-8AC02: Redundant PROFIBUS DP slave.
Replacement Control
6DL3100-8AC02: verify the complete article number, hardware revision and official project documentation before replacement.
Official Specifications
| Rated Input Voltage | 24 V DC |
|---|---|
| Static Input Range | 19.2 to 30 V DC |
| Dynamic Input Range | 18.5 to 30.2 V DC |
| Module Supply Current | 0.8 A rated |
| Load Supply Current | 8 A rated |
| Inrush Current | 3 A limited; 100 ms half-intensity width |
| Power-Failure Buffering | At least 10 ms |
| Analog Inputs | 12; six current and six configurable current/voltage |
| Analog Outputs | 8 |
| Digital Inputs | 15; three usable as count-pulse inputs |
| Configurable Digital Channels | 16 digital outputs optionally usable as inputs |
| Digital Input Delay | 50 µs |
| Digital Output Voltage | 24 V DC rated |
| Maximum Output Current | 500 mA per channel |
| Cumulative Output Current | 8 A |
| Output Short-Circuit Protection | Supported |
| PROFIBUS DP Connections | 2 for redundant operation |
| PROFIBUS DP Address Range | 1 to 125 |
Official source: Siemens Industry Mall product data for 6DL3100-8AC02. Commercial stock, warranty and shipping statements are seller terms.
Frequently Asked Questions
Can 6DL3100-8AC operate with a redundant PROFIBUS DP connection?
Yes. The module supports two DP connections and the documented single or redundant operating modes.
What distinguishes the 6DL3100-8AC02 PoCo variant during configuration?
The front-end function provides position-control processing and requires the matching PCS 7 driver and parameter set.
Which signal types can be wired to 6DL3100-8AC02?
The hardware provides analog inputs and outputs, digital inputs and outputs, and count-pulse inputs for speed acquisition.
What supply limits must be observed for 6DL3100-8AC?
Use a 24 V DC source within the specified static and dynamic ranges and size the load circuit for the documented current.
How should output loading be checked on 6DL3100-8AC02?
Keep each channel within 500 mA, observe the cumulative 8 A limit and verify protection for inductive loads.
Can the digital outputs of 6DL3100-8AC be used as inputs?
Yes. The sixteen configurable channels can be operated as inputs when the selected configuration supports that mode.
What should be saved before replacing 6DL3100-8AC02?
Archive the hardware configuration, GSD assignment, DP addresses, front-end parameters, channel mapping and redundancy settings.
Compatibility & Ordering Notes
Compatibility Checklist for 6DL3100-8AC02
- Match the complete article number 6DL3100-8AC02 without shortening the suffix.
- Confirm the installed SIMATIC PCS 7 family and hardware revision.
- Verify Redundant PROFIBUS DP slave.
- Confirm included connectors, memory media and accessories in the written quotation.
