Siemens · SIMATIC NET PROFIBUS OLM
6GK1503-3CB00 PROFIBUS OLM/G12 V4.0 Optical Link Module
The OLM/G12 V4.0 couples one electrical RS485 PROFIBUS segment to two glass-fiber channels and supports standard optical distances up to 2850 m.
At a Glance
| Brand | Siemens |
|---|---|
| Model | 6GK1503-3CB00 |
| Product Type | Optical PROFIBUS link module |
| Core Function | Converts and repeats PROFIBUS between one RS485 segment and two glass-fiber channels |
| Application or Compatible Series | PROFIBUS networks requiring redundant optical rings or long glass-fiber links |
Exact Identification
Match 6GK1503-3CB00 character by character and confirm the complete PROFIBUS OLM/G12 V4.0 Optical Link Module designation.
Interface Arrangement
Confirm the installed supply, ports, field connections and required accessories before wiring the replacement.
Configuration Check
Preserve the approved engineering project, network parameters and application data used by the installed system.
Product Overview
The OLM/G12 V4.0 couples one electrical RS485 PROFIBUS segment to two glass-fiber channels and supports standard optical distances up to 2850 m.
One RS485 interface and two optical channels connect mixed PROFIBUS media. The specified standard glass-fiber distance reaches 2850 m. A signaling contact and measuring output support diagnostics.
Key Functions
Electrical and Optical Coupling
One RS485 interface and two optical channels connect mixed PROFIBUS media.
Long Optical Distance
The specified standard glass-fiber distance reaches 2850 m.
Service Signals
A signaling contact and measuring output support diagnostics.
Official Specifications
| Device Version | OLM/G12 V4.0 |
|---|---|
| Electrical Interfaces | 1 x RS485 |
| Optical Interfaces | 2 glass-fiber channels |
| Optical Sockets | 4 x BFOC |
| Maximum Standard Distance | 2850 m |
| Signaling Contact | Provided |
| Measuring Output | Provided |
| Net Weight | 0.415 kg |
| Dimensions | 39.5 x 74.5 x 112 mm |
| Product Family | OLM optical link module |
| Quantity Unit | 1 piece |
| Lifecycle Status | Active product |
