Overview
Place of Origin: |
Sweden |
Brand Name: |
ABB |
Model Number: |
PM511V16 3BSE011181R1 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Dimensions |
3x33.3x29.7cm |
|
Weight |
0.74 kg |
|
Rated Voltage |
380 VAC (three-phase four-wire) |
|
Current Measurement Range |
1A / 5A (CT secondary input) |
|
Energy Accuracy |
Class 1 (≤1% active energy error) |
|
Communication Interface |
Modbus RTU/TCP; RS-485; RS-232; Ethernet |
|
Additional Functions |
Harmonic analysis (THD); voltage imbalance monitoring |
|
Protection Level |
IP20 |
|
Operating Temperature Range |
-20°C to +60°C (-10°C to +55°C typical) |
|
Processor Type |
32-bit microprocessor |
|
Memory |
RAM 512 KB; Flash ROM 1 MB |
|
Input Voltage |
24 VDC |
|
Power Consumption |
~10 W |
|
Programming Language |
IEC 61131-3 standard |
|
RoHS Compliance |
Directive 2011/65/EU compliant |
|
WEEE Category |
5. Small Equipment (≤50 cm) |
|
Number of Batteries |
0 |
Description
ABB PM511V16 3BSE011181R1 is a high-performance Processor Module desianed for ABB Advant Controller 450 series control systems.As the core com ponent of the Advant OCS platform, PM511V16 3BSE011181R1 is responsible for executing control programs, managing system resources, and handling communications with I/O modules and upper-level monitoring systems.
Applications
Precision electronics assembly plant: Utilizes 16/16 I/O interfaces to precisely control the coordinated operation of multiple sensors and actuators on automated assembly lines.
Food and beverage processing plant: Monitors the logical sequence of packaging lines in wide-temperature environments, with IP20 protection ensuring circuitry is protected from drying impurities.
Metal parts factory: Used for auxiliary logic control of CNC machine tools, managing peripheral equipment such as coolant pumps and safety door sensors.
HVAC management plant: Monitors fan status and temperature control switches in large building control rooms, ensuring signal feedback from the energy management system.
Features
High Performance: Employs an advanced processor, providing high-speed processing capabilities for real-time handling of large amounts of data.
Flexible Configuration: Modular design allows for flexible configuration to meet diverse application needs, offering strong scalability.
High Reliability: Rigorously tested for high reliability, ensuring stable system operation.
Good Compatibility: Highly compatible with other ABB products, allowing for easy integration into existing systems.
Rich Functionality: Supports multiple communication protocols and offers a wealth of functions, such as data acquisition, process control, and human-machine interaction.
FAQ
Q: What control input voltage does the PM511V16 3BSE011181R1 require?
A: 24 VDC low-voltage supply, ~10 W power.
Q: Can the PM511V16 3BSE011181R1 analyze grid harmonics and power quality?
A: Yes, supports THD and voltage imbalance monitoring.
Q: What voltage and current inputs does the PM511V16 3BSE011181R1 accept?
A: 380V AC three-phase input and 1A/5A CT signals.
Q: What processor and memory does the PM511V16 3BSE011181R1 use?
A: 32-bit CPU with 512 KB RAM and 1 MB Flash.
Q: What is the physical design and maintenance requirement of the PM511V16 3BSE011181R1?
A: Compact IP20 industrial device, battery-free and maintenance-free.
