Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
MU-TAMT03 51309223-125 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model: |
MU-TAMT03 51309223-125 |
|
Product Type: |
Low Level Analog Input Multiplexer |
|
Input Channels: |
32 (galvanically isolated) |
|
Input Types: |
Thermocouple; RTD; linear millivolts |
|
A/D Converter Resolution: |
14-bit |
|
TC Resolution: |
10 µV/bit (J, K, E, T, B, S, R, RP) |
|
RTD Resolution (100 Ω / 120 Ω): |
64 mΩ/bit |
|
RTD Resolution (10 Ω): |
8 mΩ/bit |
|
Linear mV Resolution: |
20 µV/bit |
|
Common Mode Voltage (CMV): |
250 VAC peak or ±250 VDC |
|
Dielectric Strength: |
1500 VAC RMS or ±1500 VDC |
|
Crosstalk: |
120 dB (DC–60 Hz) |
|
Input Impedance: |
≥2 MΩ @ 100 mV |
|
Maximum Continuous Input (no damage): |
-1 V to +10 V |
|
Input Scan Rate: |
32 samples/sec (each channel once per second) |
|
Line Frequency Sync: |
50/60 Hz configurable |
|
Hardware Accuracy: |
±40 µV or ±160 mΩ @ 23.5°C ±2°C |
|
Software Accuracy: |
±0.1°C typical; ±0.5°C max |
|
Surge Withstand Capability: |
ANSI/IEEE C37.90.1-1978 |
|
Dimensions: |
12.1 × 5 × 30.8 cm |
|
Weight: |
0.76 kg |
Description
The Honeywell MU-TAMT03 51309223-125 Low Level Analog Input Multiplexer is used to interface low-level analog input signals to Honeywell's programmable logic controllers (PLCs), ensuring accurate signal processing and protection against electrical noise and transients.
Applications
Thermal power plant: High-density thermocouple and RTD monitoring for generators, transformers, and steam piping.
Glass and chemical plants: Isolated acquisition of S/R/B thermocouples from high-temperature furnace zones.
Aluminum smelting plant: Multi-point temperature measurement under strong EMI and high ground potential conditions.
Waste-to-energy plant: Thermal zone monitoring in incinerators with strong noise and surge immunity.
Oil and gas refining plant: Dense thermocouple scanning in cracking furnaces with high channel isolation.
Features
Wide Input Range: Suitable for various industrial applications
High Accuracy: Ensures precise measurements
Low Noise: Minimizes signal interference
Robust Design: Built to withstand harsh industrial environments
Easy Integration: Compatible with various industrial control systems
FAQ
Q: How many input channels does MU-TAMT03 51309223-125 have?
A: This model has 32 isolated input channels.
Q: What is the A/D converter resolution of MU-TAMT03 51309223-125?
A: Its A/D converter resolution is 14 bits.
Q: What is the dielectric strength of MU-TAMT03 51309223-125?
A: Its dielectric strength is 1500 VAC RMS or ±1500 VDC.
Q: What is the non-destructive maximum continuous input voltage range of MU-TAMT03 51309223-125?
A: Its range is -1 V to +10 V.
Q: What is the input scan rate of MU-TAMT03 51309223-125?
A: Not specified in the provided data.
