Overview
Place of Origin: |
Sweden |
Brand Name: |
ABB |
Model Number: |
MEM86-3*192 CMBMR3 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Part Number |
MEM86-3*192 CMBMR3 |
|
Product Type |
Memory Board |
|
Dimensions |
1.8×18.4×26 cm |
|
Weight |
0.5 kg |
|
Storage Capacity |
192 KB |
|
Operating Voltage |
24 VDC |
|
+5V Current |
1.2 A / 0.003 mA |
|
Operating Temperature Range |
-20°C to +85°C |
Description
The ABB MEM86-3*192 CMBMR3 Memory Board is a high-capacity memory module designed for industrial automation systems, offering unparalleled reliability and efficiency. This specialized expansion card provides critical data storage capacity with a 3*192 memory architecture, optimized for managing complex switching logic and motion profiles.
Applications
Precision machine tool factories: Used to store complex CNC machining paths and multi-station tool compensation data.
High-speed packaging factories: Manage hundreds of electronic cam curves on packaging lines, enabling instantaneous response to specification changes.
Semiconductor manufacturing plants: Deployed in automated material handling systems within cleanroom environments to record precise positioning coordinates.
Steel smelting plants: Suitable for process control systems operating in extreme temperature environments, ensuring the long-term stability of stored data.
Tobacco machinery factories: Real-time retrieval and storage of large amounts of logic interlocks and offset parameters in high-speed cigarette making equipment.
Features
High reliability: Uses non-volatile memory to ensure data retention during power loss or restart. Built-in ECC detects and corrects minor memory errors, improving system stability.
High storage efficiency: Optimized memory architecture enables fast data access and improved overall system performance.
Easy integration: Compatible with ABB platforms such as AC 800M, supporting quick configuration and data synchronization. Standard interfaces allow tool-free installation and easy maintenance.
Status monitoring: LED indicators provide real-time memory status and fault diagnostics for fast troubleshooting.
FAQ
Q: What is the main use of MEM86-3*192 CMBMR3 192KB storage?
A: Used for industrial control logic, storing cam switch points and process parameter tables.
Q: Does MEM86-3*192 CMBMR3 support +5V and 24V power?
A: Yes. Powered by 24VDC with internal conversion to +5V (1.2A) for logic.
Q: Why does MEM86-3*192 CMBMR3 retain data after power loss?
A: Uses non-volatile memory or ultra-low power design (0.003mA quiescent current).
Q: Is MEM86-3*192 CMBMR3 rack mount compatible?
A: Yes. Its 1.8×18.4×26 cm ultra-thin design suits embedded or slot installation.
Q: What is the risk below -20°C for MEM86-3*192 CMBMR3?
A: Low temperatures may slow response or cause read errors; preheating is recommended.
