Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
MC-TLPA02 51309204-175 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model: |
MC-TLPA02 51309204-175 |
|
Product Type: |
Power Adapter |
|
Dimensions: |
15.1 × 12 × 5 cm |
|
Weight: |
0.28 kg |
|
Input Voltage Range: |
85–265 VAC |
|
Output Voltage: |
24 VDC |
|
Output Current: |
25 A |
|
Circuits: |
2 |
|
Terminal Type: |
Compression terminals |
|
Size Class: |
A (6 in / 152 mm) |
|
Conformal Coating: |
Yes |
Description
The MC-TLPA02 51309204-175 is an industrial-grade Power Adapter used for stable and continuous power delivery in distributed automation and control systems. Designed for high-availability industrial environments, it provides reliable DC power conversion for controllers, I/O modules, and field devices across complex manufacturing networks.
Applications
Oil & gas plant: Supplies power for distributed valve groups and ESD systems, supporting high-load control networks.
Power plant: Provides stable DC power for digital I/O cabinets, wide-voltage design adapts to unstable grids.
Chemical plant: Powers multiple 4–20mA transmitters, conformal coating protects against corrosive gases.
Automotive plant: Installed in local welding or stamping control boxes, compact design saves cabinet space.
Water treatment plant: Powers pump station switches and level control loops, dual-circuit design improves isolation reliability.
Wiring and Installation
Internal Installation:
When the IOP and Power Adapter are in the same cabinet, use a 51304465-xxx cable (30–300 cm). The cable has two shielded twisted pairs, with shield grounding only at the Power Adapter side. Connections use compression terminals: 6-terminal at the Power Adapter and 4-terminal at the FTA.
External Installation:
When installed in separate cabinets, use a MU-KFTSxx cable (up to 50 m). Maximum external cable length is 300 m (1000 ft). MU-KLXxxx cabinet cable uses four wires with braided shield, grounded at both the Power Adapter and FTA ends.
Features
Screw and Compression Terminal Options
CE Compliant Options
Conformally Coated Options
FAQ
Q: What is the input voltage range of MC-TLPA02 51309204-175?
A: Its input voltage range is 85–265 VAC.
Q: What is the output voltage of MC-TLPA02 51309204-175?
A: Its output voltage is 24 VDC.
Q: How much output current can MC-TLPA02 51309204-175 provide?
A: This model provides an output current of 25 A.
Q: How many circuits does MC-TLPA02 51309204-175 have?
A: It has 2 circuits.
Q: Does MC-TLPA02 51309204-175 feature conformal coating?
A: Yes, this model is equipped with conformal coating.
