Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
MC-TAIH04 51305900-175 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model: |
MC-TAIH04 51305900-175 |
|
Product Type: |
High-Level Analog Input Module |
|
Dimensions: |
12.7x4.5x15.7cm |
|
Weight: |
0.8 kg |
|
Input Channels: |
16 |
|
Signal Type: |
4–20 mA current; 1–5 V; 0–10 V |
|
Communication Protocol: |
HART (Highway Addressable Remote Transducer) |
|
Termination Type: |
Compression terminals |
|
Conformal Coating: |
Yes |
|
Redundancy Support: |
Not supported |
|
Operating Temperature Range: |
-40°C to +85°C |
Description
The Honeywell 51305900-175, also known as the MC-TAIH04, is a High-Level Analog Input (HLAI) module equipped with HART communication capabilities. Used for Honeywell's TDC 3000 Distributed Control System (DCS), this module facilitates the acquisition of analog signals from field instruments, ensuring accurate data transmission to the control system. Its conformal coating enhances durability, making it suitable for various industrial environments.
Applications
Fine Chemical Plants: Connects HART transmitters for analog and diagnostic data acquisition.
Power Plants: Accepts voltage signals for speed and position control with high channel density.
Crude Oil Transfer Plants: Operates in outdoor remote cabinets under extreme temperature conditions.
Non-Ferrous Smelting Plants: Collects multi-point furnace data with vibration-resistant terminal connections.
Paper and Fiber Plants: Acquires dense temperature and humidity signals with moisture protection coating.
Functions
FTA (Field Terminal Assembly) Positioning: Serves as a physical connection and signal distribution bridge between external field instruments (such as pressure, flow, and temperature transmitters) and IOP (Input/Output Processor) cards within the control system cabinet.
HART Signal Transparent Transmission: While maintaining 4-20 mA analog control signal transmission, the onboard circuitry allows for the superimposed transmission of high-frequency digital signals using the HART protocol, enabling asset management software in the control room (such as AMS) to directly read diagnostic information, ranges, and parameters from field smart instruments.
