Overview
Place of Origin: |
USA |
Brand Name: |
GE |
Model Number: |
GS9208/IR2 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Description |
Specification |
|
Model |
GS9208/IR2 |
|
Part name |
Infrared Flame Detector |
|
Dimensions |
16.5x13.5x14cm |
|
Weight |
1.52kg |
|
Operating principle |
Infrared detection technology |
|
Detection range |
24/7 continuous monitoring |
|
Detection sensitivity |
0.1–1.0 kW/m² |
|
Response time |
Less than 2 seconds |
|
Operating temperature |
-20°C to +55°C |
|
Humidity resistance |
Up to 95% non-condensing |
|
Power consumption |
5.0 W (max) |
|
Operating voltage |
AC 115V / DC 24V |
|
Installation type |
Surface or conduit mounting |
|
Material |
Stainless steel housing, flame-resistant components |
|
Certifications |
UL, CE, CSA approved |
Description
The GE GS9208/IR2 Infrared Flame Detector is an advanced safety solution designed for industrial environments, offering precise detection and reliable operation to prevent hazardous situations caused by fires.
Applications
LPG Storage Plants: Monitor tanks and pumping stations for fuel leak fires.
Thermal Power Plants: Detect fire risks in coal conveyor and fuel storage areas.
Fine Chemical Refineries: Provide continuous monitoring for flammable reaction zones.
LNG Plants: Monitor leaks and trigger safety interlocks in extreme environments.
Paint & Spraying Plants: Provide fire early warning in high solvent environments.
Maintenance and Troubleshooting
Troubleshooting: If the detector displays a communication failure, check the stability of the input power supply. If frequent false alarms occur, clean the dust or oil from the optical window to ensure the infrared lens's penetration is not affected.
Maintenance Recommendations: It is recommended to conduct a smoke or simulated fire source test quarterly to verify the sensor system's triggering logic. Because the detector involves life safety, use a dedicated anti-static cloth when cleaning the optical window and ensure the stainless steel casing's grounding protection is intact.
FAQ
Q: What detection level does GS9208/IR2 achieve?
A: It detects early fires in the 0.1–1.0 kW/m² range.
Q: How fast is GS9208/IR2 alarm response?
A: Less than 2 seconds for fire detection and alarm.
Q: Can GS9208/IR2 operate in extreme environments?
A: Yes, from -20°C to +55°C with high humidity resistance.
Q: What power supply does GS9208/IR2 support?
A: It supports AC 115V and DC 24V inputs.
Q: What is power consumption of GS9208/IR2?
A: Up to 5.0 W for low-power continuous monitoring.
