Overview
Place of Origin: |
Sweden |
Brand Name: |
ABB |
Model Number: |
GJR2332300R0100 88FV01E |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Quick Detail
|
Dimensions: |
2×25.8×26.1 cm |
|
Weight: |
0.4 kg |
|
Product Type: |
Relay Module |
|
Channels: |
2 relay outputs |
|
Nominal Load Current: |
8 A per channel |
|
Input Voltage Range: |
24 VDC–250 VAC |
|
Supported Loads: |
Motors, solenoids, lamps |
|
Status Indicators: |
LED indicators for each relay |
|
Manual Control: |
Built-in test button |
|
Protection: |
Short circuit and overload protection |
|
Output Type: |
Form A (SPST) relay contacts |
Description
The ABB GJR2332300R0100 88FV01E is a Master Station Modem Module that is part of the Relion family of protection and control relays, suitable for a variety of applications including power distribution, industrial automation and substation automation. It features a compact 3U footprint designed for installation in relay panels or distribution cabinets. This module offers extensive input and output signal options along with various communication capabilities, ensuring flexibility and adaptability to specific application requirements.
Applications
Large Thermal Power Plants:
Coordinated Control System (CCS): Responsible for load coordination calculations between boilers and turbines.
Automatic Generation Control (AGC): Processes grid dispatch instructions and translates them into power allocation for units within the plant.
Combustion Optimization Control: Calculates the air-fuel ratio in real time to optimize boiler efficiency and reduce emissions.
Nuclear Power Plants: Used to control auxiliary cooling systems, monitor conventional island thermal parameters, and handle complex non-safety level logic interlocks.
Combined Cycle Plants: Performs heat balance calculations and complex sequential control logic between gas turbines and waste heat boilers (HRSG).
Central Heating and Cogeneration (CHP): Manages complex extraction steam pressure control and heat distribution algorithms for multi-stage heat exchange stations.
Large-scale Metallurgical and Petrochemical Industries: Used for pressure/flow decoupling control of blast furnace blast systems or complex surge prevention calculations for large compressor units in refineries.
Specifications
|
Switching Power: |
88 VA per channel |
|
Contact Material: |
AgSnO |
|
Operating Temperature Range: |
−25 °C to +55 °C |
|
Storage Temperature Range: |
−40 °C to +85 °C |
|
Mounting: |
DIN rail mount |
|
Life Expectancy: |
~10 million operations |
Key Features
3U footprint for installation
Wide range of input and output signals
Various communication options
Highly configurable
