Overview

Place of Origin:	USA
Brand Name:	ASCO
Model Number:	E909PA16MU1
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Model	E909PA16MU1
Brand	ASCO
Product Type	Electronic Valve Controller / Sequencer
Standard Supply Voltage	115V or 230V AC
Output Voltage	24 V DC
Maximum Load Power Per Channel	25 W
Enclosure Protection Rating	IP65
Operating Ambient Temperature	–10 °C to +50 °C
Storage Temperature Range	–20 °C to +85 °C
LED Indicators	Display valve controller status and active outputs
Shell Material	ABS (Acrylonitrile-Butadiene-Styrene), Gray
Weight	0.38 kg

Description

The E909PA16MU1 Electronic Valve Controller by ASCO is designed for industrial automation, controlling solenoid valves in dust collectors and automated systems. Operating at 115 V or 230 V AC and outputting 24 V DC, the E909PA16MU1 handles up to 25 W per channel with IP65-rated ABS housing. Equipped with 1 output relay and 2 volt-free digital inputs, the E909PA16MU1 supports auxiliary control and external signals. Front-facing LED indicators display valve status and active outputs, while the 3-key programming interface and 3-digit LED display enable precise pulse and interval adjustments. The E909PA16MU1 includes selectable supply/output voltage, short-circuit output protection, and additional cycle modes for post-cleaning or extended operations. Operating from –10 °C to +50 °C and storing safely between –20 °C to +85 °C, the E909PA16MU1 weighs 0.38 kg, making it compact for panel installation. This module delivers reliable valve sequencing, real-time monitoring, and programmable control, optimizing automation workflows and ensuring efficient operation of industrial solenoid systems.

Applications

Application 1: Sequential Valve Control in Dust Collectors
The E909PA16MU1 coordinates up to 48 solenoid valves in sequential mode. By controlling 25 W per channel and precise pulse intervals of 0.1–5 s, the E909PA16MU1 ensures efficient cleaning cycles while minimizing compressed air consumption.
Application 2: Automated Compressed Air Systems
With 24 V DC outputs and 2 digital inputs, the E909PA16MU1 manages solenoid valves delivering airflow to multiple stations, allowing up to 25 W per channel load. This ensures consistent air supply and precise timing for industrial automation tasks.
Application 3: Auxiliary Process Control
The E909PA16MU1 integrates 1 output relay and LED status indicators to signal faults or trigger alarms. Operators can monitor active outputs in real time, improving response for processes handling 25 W per channel.
Application 4: Programmable Pulse Management
Using the E909PA16MU1 3-key interface and 3-digit display, engineers adjust pulse and interval times (0.1–5 s) for solenoid valves. This reduces wear on components while ensuring precise actuation in high-cycle applications.

Specifications

Output Relay	1 (for group alarm or auxiliary control)
Digital Inputs	2 (volt-free inputs for external control signals)
Programming Interface	3 programming keys and 3-digit LED display
Adjustable Pulse/Interval Times	Programmable solenoid timing settings
Short-Circuit Output Protection	Per-output protection provided
Additional Cycle Modes	Post-cleaning or extended cycle options
Selectable Supply/Output Voltage	Adjustable via jumper settings

Competitive Advantage

Competitive Advantage 1: Multi-Voltage Operation
The E909PA16MU1 supports 115 V or 230 V AC supply and 24 V DC output, enabling flexible installation across diverse automation setups.
Competitive Advantage 2: Real-Time Status Monitoring
LED indicators on the E909PA16MU1 provide immediate feedback on valve status and active outputs, allowing operators to detect issues without tools.
Competitive Advantage 3: Compact Industrial Design
Weighing 0.38 kg with IP65 ABS housing, the E909PA16MU1 fits easily into control panels while protecting electronics from dust and moisture.
Competitive Advantage 4: Programmable and Protected Outputs
Selectable voltage, adjustable pulse/interval times, additional cycle modes, and short-circuit protection on the E909PA16MU1 ensure precise control and safe operation of solenoid valves.

FAQ

Is E909PA16MU1 brand new or refurbished?

E909PA16MU1 is brand new and come with a one-year warranty.

How long will it take for the E909PA16MU1 to arrive after I place an order?

Once payment is confirmed, we ship immediately. Delivery typically takes 3-5 days from China to your location.

Do you offer any discounts?

Yes! For discounts on E909PA16MU1, please contact John for the best offer.

Do you have it in stock?

Yes, right now we have E909PA16MU1 in stock ready for shipment, we can support video inspection.

Do you provide warranty as standard?

We provide a full 12-month warranty for the E909PA16MU1. So, if you have any problems within 12 months from the date of delivery, then you can contact our Team who will be happy to help and explain what your next steps should be.
