Overview
Place of Origin: |
USA |
Brand Name: |
GE |
Model Number: |
DS200SIOBH1A |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Quick Detail
|
Dimensions |
2x18.6x26.1 cm |
|
Weight |
0.38 kg |
|
User Memory |
64 MB battery-backed and non-volatile flash memory |
|
Data Storage |
Program, configuration, register data, and symbolic variables |
|
Memory Access |
Referenced via %W table |
|
Configurable Memory |
Data and program memory |
|
Programming Languages |
Ladder logic, C, structured text, function block diagram |
|
Symbol Variables |
Auto-located, supports unlimited user memory |
|
Supported I/O |
Series 90-70 discrete and analog I/O, communication, and other modules |
Description
The DS200SIOBH1A is an I/O control board developed by GE. It is part of the MarkV control system. It provides a range of functions, enabling it to control various input/output functions. The board is designed to work with other components in the control system, and its functionality is tailored to meet the needs of industrial control applications. LEDs on the board provide visual feedback on system status, such as fault occurrences, I/O activations, etc. LEDs can be used to troubleshoot system problems or monitor system performance. A 40-pin connector on the board allows communication with other components in the system, such as the central processing unit (CPU) or other I/O modules. This connector can be used to connect to other connectors on the board using ribbon cables, which transmit signals between the board and other components in the driver.
Features
The I/O Control Board has twenty jumpers and three switch blocks, each with six switches, for a total of 18 switches. It also includes an LED and a 40-pin connector. Some connectors on the board can be synchronized and connected using ribbon cables. The ribbon cable carries numerous small wires that transmit signals from the board to other components in the driver. Other wires in the ribbon cable transmit signals to the board for processing.
Keeping the ribbon cable in good condition is crucial for signal transmission. Several guidelines must be followed. If you attempt to pull the ribbon cable while holding the ribbon section, the connection between the ribbon cable and the plastic connector may break. The best method is to firmly grasp the plastic connector with one hand and pull it out of the board's connector.
Because the signals carried by the cable are susceptible to current interference, careful cable routing within the driver is essential. Separating the cable from current-carrying cables avoids interference. Cable routing can also obstruct proper airflow, which is crucial for cooling. Driver components generate heat, which is carried away by airflow.
Specifications
|
Module Compatibility |
All non-GE Fanuc VME modules supported by Series 90-70 |
|
Network Monitoring |
PLC data accessible over network, supports up to 16 web servers and FTP connections |
|
Program Blocks |
Up to 512 blocks, each 128 KB in size |
|
Test Edit Mode |
Allows easy testing of modifications to running programs |
|
Mid-Bit Referencing |
Supported |
|
Calendar Clock |
Battery-backed |
Embedded Ethernet interface
− Data exchange using Ethernet Global Data (EGD)
− TCP/IP communication services using SRTP
− Modbus TCP server
− Complete PLC programming and configuration services
− Integrated power plant management and diagnostic tools
− Two full-duplex 10BaseT/100BaseT/TX (RJ-45 connector) ports with internal networking
