DS200SDCCG1AGD Drive Control Card

Overview

Place of Origin:	USA
Brand Name:	GE
Model Number:	DS200SDCCG1AGD
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Description

DS200SDCCG1AGD is a Drive Control card developed by General Electric under the Mark V series. It is the drive's primary controller. The GE Drive Control Board is equipped with three microprocessors and RAM that can be accessed simultaneously by multiple microprocessors

If an error occurs, ten LEDs on the GE Drive Control Board are utilized to indicate fault codes.The ten LEDs are arranged in a row and display the fault code when they are all lit up. The LEDs are lighted in a sequence of two LEDs at a time from left to right if no problem is detected and the board is running smoothly. You can inspect the LEDs by opening the board cabinet door, locating the board, visually inspecting the LEDs, and determining the board's condition.

However, because of the high voltage present in the boards and all components, caution should be exercised when opening the board cabinet door. While the drive is being powered up, do not touch anything in the cabinet

Also, make sure nothing falls inside the cabinet while the door is open, and close it after the inspection is finished. When you initially turn on the board, you'll need to set up the configuration parameters to specify how it will analyze data and regulate the drive.

There are software programs that can be used to change the parameters. On a laptop, the tools are ready for usage. If you need to set up many drives, you can generate a single configuration and download it to numerous boards.The GE Motors and Industrial Systems Drive Control Card Manual (GEI-100029) is a component-specific manual

Applications

The GE-DS200SDCCG1AGD and DS215SDCCG1AZZ01B drive control cards are commonly used in various gas turbine control applications, such as:

Power Generation: Variable speed drives for controlling gas turbines in power plants

Oil and Gas Industry: Constant speed drives for regulating gas turbine-driven compressors and pumps

Marine Propulsion: Variable speed drives for managing marine gas turbines

Features

Precise control of drive speed and torque

Monitoring of drive parameters such as current, voltage, and speed

Fault detection and diagnosis for easy troubleshooting

Communication with the entire gas turbine control system

Rugged and durable construction suitable for harsh environments

Frequently Asked Questions

Q: What is DS200SDCCG1AGD?
A: DS200SDCCG1AGD is a Drive Control card developed by General Electric under the Mark V series.

Q: In the DS200SDCCG1AGD, what are the three primary microprocessors?
A: The three primary microprocessors are the Drive Control Processor, a Motor Control Processor, and a Co-motor Processor.

Q: On the DS200SDCCG1AGD, what is the 3PL card connection?
A: The 3PL card connector is used for connecting the LAN Communications Card to the board’s outputs.

Q: Is there a pattern to the DS200SDCCG1AGD faults?
A: Yes. Faults are displayed either in binary coded decimal (BCD) or binary form. Faults 1–399 follow a BCD pattern, while faults 400–1023 are shown in binary.
