Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
8C-TDOD51 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Part Number |
8C-TDOD51 |
|
Part Type |
Digital Output Module |
|
Dimensions |
22 x 12 x 5.5 cm |
|
Weight |
0.26 kg |
|
Redundancy |
Non-redundant |
|
Coating |
Yes |
|
Output Channels |
32 |
|
Output Type |
SINK |
|
Load Voltage |
≤30 V DC |
|
Load Current |
0.1 A per channel (max) |
|
Short Circuit Protection |
Fuses in output channels (1 fuse per 8 channels; total 4 fuses for 32 channels) |
|
Galvanic Isolation |
1000 VAC RMS (system-to-field, for user supplied field power) |
|
On-State Voltage |
≤1 V DC (at 0.1 A load) |
|
Off-State Voltage |
24 V (typical) |
|
Off-State Leakage Current |
100 µA (max) |
|
Turn-On/Turn-Off Time |
10 ms max |
|
Switchover Gap (0 current) |
0 ms (redundancy only) |
Description
Honeywell 8C-TDOD51 is an 8-channel 24V DC digital output module designed for the C300 controller, offering high-resolution control and robust performance for industrial automation systems.
Applications
Automotive Manufacturing Plants: Collects stamping and welding sensor signals.
Semiconductor Wafer Plants: Monitors robotic limit switch status.
Food Processing Plants: Receives packaging line photoelectric signals.
Pharmaceutical Plants: Monitors sterile isolation door switches.
Logistics Warehouses: Controls conveyor barcode scan triggering.
Notable Features
Extensive internal diagnostics to ensure data integrity
Optional redundancy
Safe-state (FAILOPT) behaviors
Latched, pulsed or pulse-width modulated output (per channel)
Galvanic Isolation (System to Field only with external user supplied power)
FAQ
Q: Does the 8C-TDOD51 support redundancy?
A: No, it is a non-redundant standalone module.
Q: How many output channels does the 8C-TDOD51 provide?
A: It provides 32 sinking (SINK) digital output channels.
Q: What is the load capacity of each channel on the 8C-TDOD51?
A: Maximum load voltage ≤30 V DC, maximum load current 0.1 A.
Q: How does the 8C-TDOD51 provide short-circuit protection?
A: It includes 4 built-in fuses, with 1 fuse shared by every 8 channels.
Q: How are the electrical isolation and corrosion protection features of the 8C-TDOD51?
A: Supports 1000 VAC system-to-field isolation and includes conformal coating for corrosion protection.
