Overview
Place of Origin: |
USA |
Brand Name: |
GE |
Model Number: |
6231BP10820 IC660EBA024 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Part Number |
6231BP10820 IC660EBA024 |
|
Part Type |
Genius I/O Block Electronic Assembly |
|
Dimensions |
8.5 x 9.6 x 22.5 cm |
|
Weight |
1.46 kg |
|
Operating Voltage |
18–56 V DC |
|
Supply Voltage Range |
18–56 V DC |
|
Nominal Operating Voltage |
24 / 48 V DC |
|
Power Rating |
12.0 W |
|
Compatible Module |
IC660BBA024 (4 input / 2 output analog I/O module) |
|
Compatible Terminal Base |
IC660TBA024 |
|
Input Type |
4 isolated source-type inputs |
|
Output Type |
2 analog outputs |
|
Input Signal Range |
4–24 mA |
|
Block-to-Block Isolation |
1500 V for 1 minute |
|
Channel-to-Channel Isolation |
1500 V RMS |
|
Group-to-Group Isolation |
300 V RMS |
|
LED Indicators |
2 LEDs |
|
Operating Temperature |
0°C to +60°C |
|
Storage Temperature |
-40°C to +100°C |
|
Humidity |
5–95% non-condensing |
|
Operating Vibration |
5–10 Hz, 2 in displacement (5.088 mm) |
Description
The 6231BP10820 IC660EBA024 Genius I/O Block Electronic Assembly is the core component of the Genius I/O series of combined analog input/output modules. It is typically used in conjunction with specific terminal blocks and DC-DC combined analog input/output blocks to form a complete industrial control functional unit. This component integrates various precision electronic circuits responsible for performing critical tasks.
Applications
Petrochemical Plants: Monitor pressure, flow, and temperature signals in high-interference environments.
Water Treatment Plants: Control drives and dosing systems through precise signal feedback.
Steel Smelting Plants: Maintain synchronized control in high-temperature, vibration-heavy equipment.
Automotive Manufacturing Plants: Improve response speed in distributed production line I/O systems.
Paper Mills: Provide stable signal conditioning for tension and pulp control systems.
Key Features
Designed for Genius I/O Block: Integrates directly with 6231BP10820 IC660EBA024.
32 available circuits: Supports multi-channel I/O operations in automation systems.
Wide DC operating range: Accepts 18–56 VDC for versatile field power configurations.
12/24 VDC source compatibility: Suitable for common industrial voltage levels.
Group isolation: Rated at 300 V for enhanced electrical protection.
Thermocouple block application: Supports use within Genius thermocouple I/O assemblies.
Robust construction: Built for demanding industrial environments.
Efficient power usage: Operates with a 9 W power rating for stable performance.
FAQ
Q: Does the 6231BP10820 IC660EBA024 come with a warranty?
A: Yes, we offer a free 1-year warranty of IC660EBA024.
Q: What is the DAC resolution of the 6231BP10820 IC660EBA024?
A: The 6231BP10820 IC660EBA024 has DAC resolution of 16 bits.
Q: What is the ADC resolution of the 6231BP10820 IC660EBA024?
A: The 6231BP10820 IC660EBA024 has 12-bit ADC resolution.
Q: Does the 6231BP10820 IC660EBA024 support installation to the IC660EBA104?
A: No. The 6231BP10820 IC660EBA024 is not compatible with the IC660EBA104.
