Overview
Place of Origin: |
USA |
Brand Name: |
Woodward |
Model Number: |
5464-414 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
5464-414 |
|
Product Type |
Digital Speed Sensor Module |
|
Dimensions |
2.6 × 24.8 × 26.2 cm |
|
Weight |
0.96 kg |
|
Channels |
4 total channels (3 MPU + 1 Eddy Probe) |
|
Operating Temperature |
-40°C to +70°C |
|
Relative Humidity |
5%–95% RH (non-condensing) |
|
Physical Structure |
Standard industrial rack slot card design |
|
Frequency |
50/60 Hz |
|
Phase Angle |
±10° |
|
Voltage Input |
115/230 VAC RMS |
|
Power Consumption |
≤5 W |
Description
The Woodward 5464-414 is a digital speed sensor module manufactured by Woodward. It is primarily used to measure the rotational speed of rotating machinery (such as motors and turbines) and convert it into a digital signal for processing by the control system.
Applications
Power plants: control turbine and generator speed.
Chemical plants: monitor compressor and pump speed.
Refineries: protect blower and gas compressor operation.
Pulp and paper plants: monitor drive shafts and dryer cylinder speed.
Steel plants: measure rolling mill and blast furnace blower speed.
Main Functions
Speed Measurement: High-precision measurement of the rotational speed of rotating machinery.
Signal Conversion: Converts analog speed signals into digital signals for easy computer processing.
Isolation Protection: Inputs and outputs are typically opto-isolated to improve system reliability.
Features
High Accuracy: Utilizes advanced measurement technology to ensure accurate measurement results.
High Reliability: Suitable for harsh industrial environments, offering stable operation.
Modular Design: Facilitates easy installation and maintenance.
Flexible Configuration: Supports multiple options to adapt to different application needs.
FAQ
Q: How many channels does the 5464-414 include in total?
A: Includes 4 channels in total (3 MPU channels + 1 eddy current probe channel).
Q: What AC RMS input voltage does the 5464-414 support?
A: Input voltage is 115/230 VAC RMS.
Q: What is the maximum power consumption of the 5464-414 during operation?
A: Power consumption is ≤ 5 W.
Q: What phase angle range does the 5464-414 support?
A: Phase angle is ±10°.
Q: What physical structure does the 5464-414 use?
A: Uses a standard industrial rack slot card design.
