Overview

Place of Origin:	USA
Brand Name:	HONEYWELL
Model Number:	51401635-150
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Specifications

Model	51401635-150
Product Type	HPM Communication and Control Processor
Dimensions	3.2 x 33 x 27.8 cm
Weight	1.15 kg
Status Indicators	LED status indicators
Network	Universal Control Network (UCN), 5 Mbps, token bus access control
Compatibility	Works with HPMM card set assemblies
Mounting	Occupies two left-most slot positions in card file
Power Supply	24 VDC
Operating Temperature Range	-40 °C to +70 °C
Humidity Range	5–95% non-condensing

Description

The Honeywell 51401635-150 is a HPM Communication and Control Processor performs the network communication functions of the HPM, including network data access and time-stamping. 51401635-150 Control Processor executes regulatory, logic, and sequence functions, and user programming. The Universal Control Network (UCN) is a high-speed, high-security process control network.

Applications

Petrochemical Plants: Refinery control & closed-loop processing.

Coal Gasification Plants: Gasifier interlocks & fast control.

Ethylene Plants: Cracking and separation control.

Power Plants: Boiler-turbine load coordination.

Fine Chemical Plants: Batch reactor timing control.

Features

High-Speed Communication: Facilitates rapid and reliable data exchange across Honeywell process control systems

Advanced Processing: Executes regulatory, logic, and sequence functions along with user programming

UCN Integration: Designed for Universal Control Network with secure, high-speed communication

System Compatibility: Works seamlessly with HPMM assemblies for complete communication and I/O integration

Replacement and Maintenance Guidelines

Hot-Swap Prohibition (Core Processor Risk): It is a core HPM bus processor; disconnect power before removal. In non-redundant mode, removal causes signal loss; unsafe hot-swap in redundant mode may damage adjacent cards.

Slot Misalignment Prevention: Fixed slot in 5-slot or 10-slot HPM chassis. Ensure proper alignment and secure latches; incorrect insertion may damage pins or cause short circuits.

Configuration Reload After Replacement: New or refurbished boards require reloading of process tables and control logic. Operate only when the status LED is green (RUN).

Assemblies

The HPMM card set consists of following assemblies:

High-Performance Comm/Control card replaced by (51403988-150)

High-Performance I/O Link card (51309276-150)

HPM UCN Interface module ((51402573-150)

FAQ

Q: What is the communication rate and access control method of 51401635-150 in the network?
A: It operates at 5 Mbps on the UCN and uses token bus access control.

Q: What type of card assembly is compatible with 51401635-150?
A: It is compatible with HPMM card assemblies.

Q: Where does 51401635-150 occupy slots in the rack?
A: It occupies the two leftmost slots in the card rack.

Q: What is the power supply of 51401635-150?
A: The power supply is 24 VDC.

Q: What is the operating temperature range of 51401635-150?
A: The operating temperature range is -40°C to +70°C.
