Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
51305072-100 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
51305072-100 |
|
Product Type |
CLCN-A/B LCN I/O Card |
|
Dimensions |
18 x 7 x 4 cm |
|
Weight |
0.18 kg |
|
Compliance |
CE |
|
System Compatibility |
Honeywell TDC 3000 |
|
Node Address Setting |
Slide switch addressing |
|
Cable Connections |
LCN A / LCN B cables |
|
Cable Interface |
LCN “A” coaxial cable |
|
Connector Type |
BNC tees (node disconnect without network disruption) |
|
Mounting Type |
Dual-node chassis |
|
Power Supply |
24 VDC ±10% |
|
Power Consumption |
15 W |
|
Memory Capacity |
50 MB |
|
Communication Protocol |
ControlNet |
|
Communication Speed |
5 Mbps |
|
Operating Temperature Range |
-20 °C to +55 °C |
|
Storage Temperature Range |
-40 °C to +85 °C |
|
Protection Rating |
IP20 |
Description
The HONEYWELL 51305072-100 is the CE version of the LCN I/O board for Honeywell's 5-slot and 10-slot chassis. This is the card where the LCN node address is set, and where the LCN A and B cables are connected. This version uses a slide switch for addressing.
Applications
Chemical Plants: Link LCN network for plant pressure and flow data.
Power Plants: Connect boiler and turbine control networks for fast data exchange.
Refinery Plants: Sync central control with cracking unit status.
Steel Plants: Integrate blast furnace and converter monitoring networks.
Cement Plants: Send kiln control commands from operator station.
Features
Redundant Network Support: Works with LCN Cable A; Cable B handled by CLCN-B module
Hot-Swappable: Allows online replacement without interrupting system operation
Diagnostic LEDs: Real-time status indicators for power, communication, and link health
Electromagnetic Shielding: Multi-stage filtering for signal integrity in noisy environments
Robust Connectivity: Ensures low error rate(≤1x10-3) for real-time control and data sync
FAQ
Q: What is the power supply of 51305072-100?
A: Its rated power supply is 24 VDC ±10%.
Q: What is the operating power consumption of 51305072-100?
A: Its operating power consumption is 15 W.
Q: What is the memory capacity of 51305072-100?
A: Its onboard hardware memory is 50 MB.
Q: What is the communication speed of 51305072-100 under ControlNet protocol?
A: Its data transmission rate can reach 5 Mbps.
Q: What is the operating temperature range of 51305072-100?
A: The operating ambient temperature range is -20°C to +55°C.
