Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
51304831-100 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
51304831-100 |
|
Product Type |
TPDG I/O Board |
|
Dimensions |
22.3 x 14 x 1.5 cm |
|
Weight |
0.18 kg |
|
Function |
Interface for peripherals |
|
Peripheral Connections |
6 peripheral connections |
|
Compliance |
Non-CE |
|
Configuration Controls |
On-board jumpers/pins J10 and J11 for logic configuration |
Description
The HONEYWELL 51304831-100 is a TPDG I/O Board used in process control systems. This (non-CE) TPCG I/O card is used on a UxS station the same way the EPDG I/O card us used on a Universal Station - to provide the interface for the peripherals controlled by the TPDG card.
Applications
Chemical Plants: Interface safety systems for pressure and flow control.
Power Plants: Collect turbine vibration and speed signals.
Steel Plants: Transfer batching and limit switch data.
Cement Plants: Monitor motor current and bearing temperature.
Paper Plants: Process pulp density and flow signals.
Troubleshooting
Peripheral display grayscale anomaly/blurry text: Check jumper J10/J11 status and reconfigure grayscale logic per display manual.
Specific peripheral channel not recognized: Check pin oxidation of 6 peripheral connections or signal attenuation in long cables.
Multi-channel simultaneous communication interruption: Check backplane power contact and transient EMI on rack bus.
FAQ
Q: What is the main function of 51304831-100?
A: Its main function is an interface for peripherals.
Q: How many peripheral connection points does 51304831-100 have?
A: It provides 6 peripheral connections.
Q: Does 51304831-100 comply with CE certification?
A: No, it is non-CE certified.
Q: How is logic configuration controlled in 51304831-100?
A: It uses onboard jumpers/pins J10 and J11 for configuration control.
