51304685-100 Advanced Communications Card, China 51304685-100 Advanced Communications Card Manufacturers, Suppliers, Factory

Overview

Place of Origin:	USA
Brand Name:	HONEYWELL
Model Number:	51304685-100
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Specifications

Model	51304685-100
Product Type	Advanced Communications Card
System Compatibility	APM R400
Special Feature	Includes time sync daughter board
Mounting Type	Clamp mount
Power Supply	Panel-supplied DC power
Input Voltage	24 VDC (typical)
Voltage Protection	Over-voltage and surge protection included
Cooling Method	Natural air convection
Operating Temperature Range	0 °C to +60 °C
Storage Temperature Range	-40 °C to +85 °C
Noise Level	Negligible
Efficiency	High
Material	Industrial-grade PCB; robust enclosure

Description

The 51304685-100 is an Advanced Communications Card used in process automation systems. This module provides network communication with the UCN and provides high-accuracy time stamps. It is primarily used for connecting and coordinating advanced communications within a control system network.

Applications

Chemical Plants: Connect DCS with workshop control stations for data exchange.

Power Plants: Link main plant and auxiliary systems for centralized monitoring.

Steel Plants: Network blast furnace control with raw material and sintering systems.

Automotive Plants: Connect shop floor control with MES production scheduling.

Semiconductor Plants: Integrate micro-control networks with central monitoring system.

Physical Environmental Protection Limitations for the Suffix

Non-coated (Uncoated Version): The -100 model number indicates that the circuit board surface is not covered with Conformal Coating. This version must be deployed in a control room or a well-ventilated industrial control cabinet equipped with standard air conditioning and positive pressure ventilation.

Core Functions and Built-in Daughter Board Roles

UCN High-Speed Network Communication Hub: The 51304685-100 connects the APM controller to the UCN (Universal Control Network). It performs high-speed process data communication, enabling fault-tolerant communication between the APM node, operator stations, and other UCN nodes.

Time-Sync High-Precision Timestamps: The built-in 51401598-100 Time-Sync Daughter Board provides millisecond-level synchronized timestamps for process variables, I/O changes, alarms, and SOE records, ensuring accurate plant-wide event sequencing.
