Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
51304518-150 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
51304518-150 |
|
Product Type |
Advanced Control Module (R400) |
|
Application |
Advanced Process Manager (APM) |
|
Processor |
ARM Cortex-A9 |
|
Memory |
1 GB |
|
I/O Capacity |
Up to 256 points |
|
Communication Interfaces |
RS-232; RS-485; Ethernet; Modbus; BACnet |
|
Power Supply |
24 VDC |
|
Dimensions |
22.2 x 17.6 x 8.9 cm |
|
Weight |
2.3 kg |
|
Operating Temperature Range |
-40 °C to +70 °C (-40 °F to +158 °F) |
|
Storage Temperature Range |
-40 °C to +85 °C (-40 °F to +185 °F) |
|
Relative Humidity |
5% to 95% (non-condensing) |
|
Protection Rating |
IP67 |
Description
The 51304518-150 is an Advanced Control Module used to regulate control, logic operations, and sequence control functions within process control systems. This module is widely used in industrial automation and process industries that require stable, high-precision control and continuous operation.
Applications
Heavy fertilizer chemical plant: Controls high-density I/O for reactor systems in outdoor or humid environments.
Natural gas compression station: Enables remote control of multi-vendor equipment in unmanned field sites.
District heating plant: Provides integrated BACnet control across wide-area and variable-temperature pipeline networks.
Water treatment plant: Supports on-site control near wet filtration areas in high-humidity conditions.
Cement building materials plant: Ensures stable operation in high-dust environments such as outdoor material conveying systems.
System Positioning and Communication Role
Connecting Upper and Lower Levels: In the TDC 3000 system architecture, this card serves as the "brain" of the APM controller. It receives process variables (temperature, pressure, flow, etc.) collected from various field instruments (input modules) via its base and bus, performs high-speed calculations using preset PID algorithms or logic, and then distributes control commands to the output modules.
Peer-to-Peer Network Communication: It establishes highly reliable, bidirectional, redundant peer-to-peer communication with upper-level nodes (such as HPM, local operator stations, and network interface modules NIM) through the UCN network interface, ensuring centralized monitoring and management of plant-wide process data.
FAQ
Q: What processor and memory does the 51304518-150 Advanced Control Module (R400) use?
A: ARM Cortex-A9 processor with 1 GB memory.
Q: What is the maximum I/O capacity of the 51304518-150 in APM applications?
A: Up to 256 I/O points.
Q: What communication interfaces and protocols does the 51304518-150 support?
A: RS-232, RS-485, Ethernet, Modbus, and BACnet.
Q: What is the enclosure protection rating of the 51304518-150 with 24 VDC supply?
A: IP67.
Q: What environmental conditions does the 51304518-150 support for operation and storage?
A: Operating: -40 °C to +70 °C; Storage: -40 °C to +85 °C; 5%–95% RH (non-condensing).
