125736-01 Communication Gateway I/O Module

Overview

Place of Origin:	USA
Brand Name:	Bently Nevada
Model Number:	125736-01
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Description

The Bently Nevada 125736-01 Communication Gateway Modules provide extensive communication capabilities of all rack monitored values and statuses for integration with process control and other automation systems using both Ethernet TCP/IP and serial (RS232/RS422/RS485) communications capabilities. It also permits Ethernet communications with 3500 Rack Configuration Software and Data Acquisition Software. The Ethernet connection to the 125736-01 is an RJ45 connection for 10BASE-T star configuration Ethernet networks. The 125736-01 supports the communication interfaces, communication protocols, and other features from the original 3500/90 with the exception of the primary value Modbus registers. The 125736-01 now has a Configurable Modbus Register Utility, which can provide the same functionality originally addressed by the primary value Modbus registers.

Applications

Transmit Turbine Vibration Data to DCS

125736-01 sends vibration measurements from up to 64 3500 rack channels via Ethernet or RS485, enabling real-time monitoring. Data such as shaft vibration amplitude (measured in mils) is transmitted directly to DCS for automated control and alarm actions.

Forward Pump Temperature Alarms to Control Room

125736-01 maps temperature sensor inputs to Modbus registers. Each channel handles 0–10 VDC or 4–20 mA signals, allowing plant operators to receive alarms when pump bearings exceed 75°C.

Integrate Compressor Monitoring with Data Acquisition Software

By connecting to Data Acquisition Software, 125736-01 transmits compressor vibration (0–10 VDC), position, and temperature data, supporting automated logging and predictive maintenance.

Link Multiple 3500 Racks to Central Automation Network

Multiple 125736-01 modules in a rack aggregate monitored values and relay statuses, sending them via TCP/IP or serial networks to centralized control systems, reducing wiring complexity.

Specifications

Competitive Advantage

Map and Transmit Multiple Monitored Values Using Modbus

125736-01 allows configuration of Modbus registers for up to 3500 rack channels, reducing wiring complexity and enabling direct automation integration.

Operate in High Humidity and Temperature Cabinets

With -30°C to +65°C operation and 95% non-condensing humidity tolerance, 125736-01 can be installed near turbines, compressors, or pump stations without additional cooling.

Real-Time Status Indication on Front Panel

OK and TX/RX LEDs on 125736-01 provide immediate visual confirmation of communication and system operation, minimizing diagnostic time during maintenance.

Compact Design Saves Rack Space

At only 24.4 mm width, 125736-01 allows high-density deployment of communication modules in automation racks, supporting scalable integration of multiple 3500 monitoring channels.
