Overview
Place of Origin: |
USA |
Brand Name: |
ICS TRIPLEX |
Model Number: |
TC-505-02-8M5 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
TC-505-02-8M5 |
|
Product Type |
Trusted TMR I/O SmartSlot Cable |
|
Length |
8.5 m |
|
Application |
Digital 24 V / 120 Vdc or analog output modules |
|
Maximum Working Voltage |
60 V |
|
Maximum Current per Channel |
2 A |
|
Cable Type |
LSZH (Low Smoke Zero Halogen) |
|
System Interface |
Internal SmartSlot V2 Version |
|
Signal Channels |
40-channel input to FTA |
|
Core Configuration |
Three multi-core cables |
|
Core 1 |
96-way ‘C’ to 96-way ‘R’ for FTA connection |
|
Core 2 |
5-way Weidmuller connector for T8290 power distribution (field return) |
|
Core 3 |
6-way AMP plug for field power supply from T8290 / T8297 |
|
Chassis End Connector |
96-way Type ‘C’ connector |
|
Field End Connector |
96-way Type ‘R’ connector |
|
Certifications |
IECEx, CCC Ex, CE |
|
Installation Type |
Chassis to Field Interface Connection |
Description
The TC-505-02-8M5 is a Trusted TMR I/O SmartSlot Cable that transmits signals generated by digital or analog output modules to the internal field terminal block (FTA). This cable integrates the main control rack, field power supply circuitry, and external power distribution unit, and meets the safety and stability requirements of industrial automation systems through its outer sheath, shielded grounding, and wear-resistant construction.
Applications
Petrochemical Plants: TMR safety linkage ensures secure data acquisition and emergency shutdown in hazardous areas.
Natural Gas Processing Plants: Explosion-proof design supports stable long-distance, anti-interference signal transmission.
Thermal Power Plants: Maintains continuous communication between boiler protection and turbine control systems.
Fertilizer Plants: LSZH material reduces toxic gas risks in corrosive environments.
Offshore Drilling Platforms: High-density explosion-proof connectivity for confined and compact installations.
Competitive Advantage
Optimized Mid-Range Length: The 8.5-meter layout solves difficult cable routing across non-adjacent control panels seamlessly.
Global Compliance: Triple certified (IECEx, CCC Ex, CE) for immediate deployment in international hazardous zones.
High Power Capacity: Supports up to 120 Vdc and 2 A per channel, outperforming standard low-power signal cables.
FAQ
Q: What are the voltage and current ratings of TC-505-02-8M5?
A: Max voltage 60V, max current 2A per channel.
Q: How many FTA channels does TC-505-02-8M5 support?
A: Supports 40 input channels to FTA.
Q: What I/O modules are compatible with TC-505-02-8M5?
A: Works with 24 V/120 Vdc digital output and analogue output modules.
Q: What are the three core cables in TC-505-02-8M5?
A: Core 1 96-way C-R, Core 2 5-way Weidmuller, Core 3 6-way AMP.
Q: What certifications does TC-505-02-8M5 have?
A: IECEx, CCC Ex, and CE certified.
