30024789 TEC300247 Cable

Overview

Place of Origin:	Japan
Brand Name:	TACAN
Model Number:	REF 30024789 TEC300247
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Description

The REF 30024789 TEC300247 is a high-frequency RF coaxial cable assembly designed by TACAN Japan for automation systems requiring precise signal transmission. REF 30024789 TEC300247 features a characteristic impedance of 50Ω ±2Ω, capacitance of 82 pF/m, and can operate across a frequency range of 0.1 GHz to 2.5 GHz. With a withstand voltage of 2.5 kVrms and insertion loss ≤1.5 dB at 1 GHz, REF 30024789 TEC300247 ensures accurate signal delivery in automated testing, medical devices, and aerospace equipment. The cable tolerates extreme temperatures from –55°C to +200°C. Packaged at 2 x 19.7 x 26.1 cm and weighing 0.42 kg, REF 30024789 TEC300247 integrates easily into high-precision control systems, providing reliable data flow for sensors, actuators, and control modules.

Applications

Application: High-Precision Signal Transmission
REF 30024789 TEC300247 is used to connect high-frequency sensors and actuators in automated testing environments. Its 50Ω ±2Ω characteristic impedance and frequency range of 0.1–2.5 GHz allow accurate transmission of critical signals with minimal loss.

Application: Medical Device Automation
In medical equipment automation, REF 30024789 TEC300247 transmits high-speed data between control modules and monitoring devices. Its insertion loss ≤1.5 dB at 1 GHz ensures signals from patient sensors or imaging equipment are delivered accurately.

Application: Aerospace Control Systems
REF 30024789 TEC300247 is employed in aerospace automated control systems to link avionics modules and test instruments. Its withstand voltage of 2.5 kVrms protects sensitive circuits while operating in extreme temperature ranges of –55°C to +200°C.

Specifications

Competitive Advantage

Competitive Advantage: High-Frequency Accuracy
With a capacitance of 82 pF/m and precise 50Ω ±2Ω impedance, REF 30024789 TEC300247 minimizes signal reflection and ensures accurate high-frequency signal delivery for automated control.
Competitive Advantage: Extreme Temperature Operation
REF 30024789 TEC300247 can function from –55°C to +200°C, making it suitable for harsh industrial and aerospace environments without degradation of signal quality.
Competitive Advantage: Low Signal Loss
The ≤1.5 dB insertion loss at 1 GHz of REF 30024789 TEC300247 reduces power dissipation and preserves signal integrity for automated measurement, control, and communication systems.

FAQ

What is the REF 30024789 TEC300247?

It is a Cable.

Is this product brand new?

Yes, REF 30024789 TEC300247 is brand new, original, unused, and factory sealed

Do you have it in stock?

Yes, right now we have REF 30024789 TEC300247 in stock ready for shipment, we can support video inspection.

Why can't I see a price for this REF 30024789 TEC300247?

In addition to "new original" " units.

we also specialize in the selling "discontinued" and hard to find industrial automation parts which tend to have a fluctuating market value. These fluctuations may make it difficult for us to provide accurate daily prices for parts on our website. Therefore, in an effort to ensure that we always provide you with the best and most accurate price available, our team will source and price your part on an enquiry-by-enquiry basis.

Do you provide warranty as standard?

We provide a full 12-month warranty for the REF 30024789 TEC300247. So, if you have any problems within 12 months from the date of delivery, then you can contact our Team who will be happy to help and explain what your next steps should be.
