Overview

Place of Origin:	Sweden
Brand Name:	ABB
Model Number:	07KT93 GJR5251300R0171
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Model:	07KT93 GJR5251300R0171
Product Type:	Central Processing Unit
Program Memory:	256 KB RAM for user program and data with EEPROM backup
Backup Battery:	Lithium battery, maintains RAM data and RTC for approx. 3–5 years
Cycle Time:	Typical Boolean instruction execution time approx. 0.3 µs
Digital Inputs (DI):	24 channels (24 V DC), 2 configurable as high-speed counters up to 50 kHz
Digital Outputs (DO):	16 channels (24 V DC / 0.5 A transistor outputs)
Analog Inputs (AI):	8 channels, supports 0–10 V, 0–20 mA, 4–20 mA, Pt100, Pt1000, 12-bit resolution
Analog Outputs (AO):	4 channels, supports 0–10 V, 0–20 mA, 4–20 mA, 12-bit resolution
CS31 Bus Interface:	Built-in, supports up to 31 remote expansion modules
Serial Interface COM1:	RS-232 for programming and diagnostics
Serial Interface COM2:	Supports Modbus RTU (master/slave), RCOM or ASCII protocol
Network Capability:	Supports complex network topologies
Power Supply:	24 V DC (19.2 V to 30 V range)
Power Consumption:	Max approx. 18 W with full I/O load
Mounting Method:	DIN rail or screw mounting
Status LED RUN:	Green, normal operation
Status LED ERR:	Red, system or I/O fault
Status LED BAT:	Yellow, low battery warning
I/O LEDs:	Indicate physical status of each input and output channel

Description

The ABB 07KT93 GJR5251300R0171 industrial processor is a high-performance processor designed specifically for industrial automation. It employs advanced manufacturing processes to ensure stable operation in various harsh environments. Its superior computing power supports complex control algorithms, meeting the precision and efficiency requirements of modern industrial production.

This processor features a compact design, facilitating integration into existing industrial control systems. Its high reliability and long lifespan significantly reduce maintenance costs, making it suitable for applications requiring continuous operation. Furthermore, rigorous testing and quality control processes ensure high-quality standards for every product leaving the factory.

This processor is an ideal choice for both new production lines and factories upgrading existing systems. Its ease of use and compatibility simplify installation and commissioning. Leveraging ABB's global brand influence and strong technical support team, users can enjoy a comprehensive service experience.

Applications

Shipbuilding & Shipping:

Core Applications: This is the most competitive area for 07KT93, widely used in ship propulsion system control, power management systems (PMS), and engine room automation monitoring.

Advantages: Certified by almost all major global classification societies such as DNV, GL, LR, and ABS, capable of withstanding high vibration, high humidity, and wide temperature differences in marine environments.

Power & Energy Plants:

Plant Scenarios: Hydropower station auxiliary equipment, substation integrated automation, wind turbine generators.

Specific Uses: Used to handle complex logic interlocks and PID regulation, extending remote I/O via the CS31 bus to monitor generator operating parameters.

Water Treatment & Municipal Engineering:

Plant Scenarios: Large-scale wastewater treatment plants, municipal water booster pump stations.

Function: As the main control unit, managing the distributed control stations throughout the plant, controlling large variable frequency pumps, bar screens, and chemical dosing systems.

Metallurgy & Heavy Industry: Factory Scenarios: Conveyor belt control in steel mills, monitoring of mine hoists, control of large extrusion presses.

Function: Provides stable logic output in harsh electromagnetic interference environments.

Features

Integrated I/O Configuration:

24 digital inputs (24V DC).

16 digital outputs (transistor type).

8 analog inputs (supports multiple signal types).

4 analog outputs.

Communication Interface: Built-in CS31 bus interface, with 2 serial communication ports (configurable as Modbus master/slave).

High Reliability: Supports fast task cycles and equipped with large-capacity user program memory (RAM/EEPROM).

Competitive Advantage

High-Density Integrated Control: It integrates 24 digital inputs, 16 digital outputs, 8 analog inputs, and 4 analog outputs within a single compact module. This "full-featured" configuration allows it to independently handle complex control tasks for medium-sized machines or production lines without requiring additional expansion modules.

Superior Analog Signal Processing Capabilities: Its 12-bit high-resolution analog inputs and outputs support multiple signal types (4-20mA, 0-10V, Pt100/1000, etc.), making it particularly suitable for continuous process control such as temperature control, pressure regulation, and flow monitoring.

Powerful Distributed Expansion (CS31 Bus): The built-in CS31 system bus interface allows this unit to act as a master station, connecting up to 31 remote I/O stations via simple twisted-pair cabling. This greatly simplifies cabling for very long production lines or large plants (such as shipbuilding and water pipeline networks).

Multi-protocol communication hub: Equipped with two serial interfaces (COM1/COM2), it supports Modbus RTU, RCOM, or ASCII protocols in addition to programming. This allows it to easily interface with frequency converters, smart meters, HMI touch screens, or host computer SCADA systems.
