Overview

Place of Origin:	Sweden
Brand Name:	ABB
Model Number:	YXU144 YT296000-MC YXU 144
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Specifications

Part Number	YXU144 YT296000-MC YXU 144
Product Type	Pulse Transformer Unit
Operating Voltage Range	120–240 V AC
Frequency Response	4 kHz to 10 kHz
Power Handling Capacity	1 kVA
Insulation Resistance	≥ 10 MΩ
Temperature Range	-20°C to +50°C
Protection Class	IP20
Dimensions	12×10×6.5 cm
Weight	0.5 kg

Description

ABB YXU144 YT296000-MC YXU 144 is a high-performance pulse transformer unit in inducstrial aeras. Integrating cutting-edge technology, the ABB YXU144 YT296000-MC YXU 144 Pulse Transformer Unit offers unparalleled precision and reliability for transformer pulse management in complex industrial settings.

Applications

Power equipment manufacturers: Used in the thyristor (SCR) or IGBT trigger circuits of high-power converters to achieve electrical isolation protection.

Welding machine manufacturers: Integrated into the control board of inverter welding machines to ensure accurate conversion and stable output of high-frequency pulse current.

Induction heating equipment manufacturers: Power modules suitable for high-frequency quenching or melting equipment, handling power transmission under high-frequency response.

Medical device manufacturers: Used as pulse isolation components in high-energy X-ray equipment or laser power supplies to ensure the safety and stability of control circuits.

Rail transit equipment manufacturers: Used in locomotive auxiliary inverter systems to provide reliable pulse signal support under wide voltage fluctuation environments.

Troubleshooting and Maintenance

Troubleshooting: If the output pulse is distorted, check if the input frequency exceeds the 4kHz-10kHz range; if overheating occurs, check if the load exceeds the 1 kVA rated capacity.

Maintenance Recommendations: Given its IP20 protection rating, it should be installed in a dry, dust-free cabinet. Regularly check the tightness of the wiring terminals to prevent excessive contact resistance.

FAQ

Q: Does the YXU144 YT296000-MC YXU 144 behave differently at 120V and 240V?
A: No. It supports wide input range and maintains stable 1 kVA output across 120–240V AC.

Q: What is the role of ≥10 MΩ insulation resistance in YXU144 YT296000-MC YXU 144?
A: Ensures strong isolation between high-voltage and control circuits, protecting low-voltage electronics.

Q: Why is frequency response limited to 4–10 kHz in YXU144 YT296000-MC YXU 144?
A: This band minimizes pulse distortion and ensures accurate trigger signal transmission.

Q: Does YXU144 YT296000-MC YXU 144 require preheating at -20°C?
A: No. It supports direct cold start and full-load operation at -20°C.

Q: How to judge end-of-life for YXU144 YT296000-MC YXU 144?
A: Check insulation resistance; if it drops below 10 MΩ or core damage appears, replacement is needed.
