Overview
Place of Origin: |
USA |
Brand Name: |
ICS TRIPLEX |
Model Number: |
TC-205-02-8M5 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Part Number |
TC-205-02-8M5 |
|
Part Name |
Trusted I/O Companion Slot Cable |
|
Cable Length |
8.5 m |
|
Cable Type |
Internal, 40-channel input to FTA |
|
Cable Description |
I/O companion slot internal cable for 40-channel input to FTA |
|
Maximum Working Voltage |
60 V |
|
Maximum Current |
2 A per channel |
|
With LED Indication |
False |
|
Cable Geometry |
Round |
|
Cable Insulation Type |
Low smoke zero halogen (LS0H) |
|
Halogen Free |
True |
|
Certifications |
ATEX; China CCC; CE; IECEx Scheme; UL Listed |
|
Connector Type (End A) |
96-pin C-type connector (base companion slot) |
|
Connector Type (End B) |
96-pin R-type connector (FTA termination panel) |
Description
The ICS TRIPLEX TC-205-02-8M5 Cable is a high-quality Trusted I/O Companion Slot Cable designed for use within the ICS Triplex Trusted™ control system. It provides reliable connections between Trusted analogue and digital input/output modules and Trusted Field Terminal Assemblies (FTAs) or Trusted Universal Field Terminal Assemblies (VFTAs), ensuring stable signal transmission in safety-critical control applications.
Applications
Petrochemical plants: Safe 40-channel transmission in hazardous zones with ATEX/IECEx compliance.
Fine chemical plants: LS0H insulation reduces toxic and corrosive gas release in fires.
LNG plants: Efficient routing in large cabinet systems via high-density connectors.
Thermal power plants: Stable multi-channel integration for turbine protection systems.
Offshore drilling platforms: UL/CE certified, round design for harsh marine use.
Key Features
Trusted interconnection cable for ICS Triplex Trusted™ systems
Connects analogue and digital I/O modules to FTAs or VFTAs
Available with optional fly-wire termination for flexible wiring
Designed for use within control cabinets and adjacent enclosures
Supports secure and stable signal transmission
External cable option provides additional protection (non-armored)
Installation and Handling
Cable Protection: Non-armored
Handling Requirement: Must not be pulled by connectors
Routing: Should be securely supported and protected along cable paths
Environment: Industrial control cabinet environments
FAQ
Q1: Does TC-205-02-8M5 include LED indicators for 40-channel monitoring?
A1: No. With LED Indication is False; status is checked via software or FTA.
Q2: What are the voltage and current ratings, and is TC-205-02-8M5 for power use?
A2: 60 V and 2 A per channel; not suitable for power transmission.
Q3: Are connectors in TC-205-02-8M5 interchangeable?
A3: No. It uses 96-pin C-type and R-type connectors, which are keyed.
Q4: Does TC-205-02-8M5 meet halogen-free requirements?
A4: Yes. LS0H insulation, Halogen Free: True, low smoke and non-toxic.
Q5: What are length and geometry of TC-205-02-8M5?
A5: 8.5 m length, Round geometry for flexible routing.
