Overview
Place of Origin: |
USA |
Brand Name: |
ICS TRIPLEX |
Model Number: |
T9310-02 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
T9310-02 |
|
Product Type |
Backplane Expansion Cable |
|
Dimensions |
6.7 x 3.4 x 2 cm |
|
Weight |
0.04 kg |
|
Length |
2 m |
|
Input Voltage Range |
24 VDC |
|
Output Voltage Range |
24 VDC |
|
Operating Temperature Range |
-20 °C to +70 °C |
|
Storage Temperature Range |
-40 °C to +85 °C |
|
Humidity Range |
10% to 90% RH |
|
Connector Type |
DB37 high-density connector |
|
Pin Count |
37 Pins |
|
Accessories |
Blanking covers |
|
Installation Type |
Backplane expansion connection |
Description
The T9310-02 is a backplane expansion cable assembly manufactured under the ICS Triplex Trusted series. This cable is used to bridge and extend communication and power buses between adjacent T9300 I/O base units or system chassis.
Applications
Petroleum Refineries: Connects safety systems and transmits emergency shutdown signals.
Ethylene Plants: Expands control points and synchronizes reactor interlock data.
Thermal Power Plants: Links boiler protection and turbine control racks.
Nuclear Power Plants: Extends redundant cabinets for synchronized safety signals.
Troubleshooting
Rack communication loss or I/O bus fault—check DB37 pins for damage or oxidation; ensure connector screws are fully tightened.
24V DC voltage drop—measure supply voltage, verify load capacity, and check for cable-related micro shorts.
Bus interference—ensure cable shielding is grounded properly and avoid routing near high-voltage power cables.
FAQ
Q: What is the length of the T9310-02 expansion cable?
A: 2 meters.
Q: What input and output voltage does the T9310-02 support?
A: 24 VDC input and output.
Q: What operating temperature range can the T9310-02 withstand?
A: -20 °C to +70 °C.
Q: What connector type does the T9310-02 use?
A: 37-pin DB37 high-density connector.
Q: What humidity range is suitable for the T9310-02?
A: 10% to 90% RH.
