Overview

Place of Origin:	USA
Brand Name:	ICS TRIPLEX
Model Number:	T8901
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Specifications

Parameter	Value
Part Number	T8901
Part Name	Digital Output Module
Dimensions	26.6 × 3 × 30 cm
Weight	0.34 kg
Number of Channels	8
Rated Voltage	24 Vdc
Voltage Range	18 to 32 Vdc
Maximum Current	165 mA
Power Consumption	3 W
Scan Times	1.174 ms / 2.202 ms

Description

The ICS Triplex T8901 is a high-performance digital output module designed for industrial automation and safety-critical control systems. The module integrates seamlessly with ICS Triplex controllers and terminal assemblies, providing scalable output capacity for complex control systems.

Applications

Precision Automotive Plants: Monitors stamping lines and robot safety signals with high-speed scanning.

Smart Packaging Plants: Provides fast distributed channel response for conveyor sensor data.

Petrochemical Plants: Supports wide-voltage operation for stable process monitoring over long cables.

Electronics Manufacturing: Low-power design ensures stable operation in cleanroom control cabinets.

Water Treatment Plants: Collects distributed valve and pump status for continuous process control.

Key Features

Eight Digital Output Channels: Supports precise digital signaling for industrial control applications.

Dual Scan Times: Operates at 1.174 ms and 2.202 ms, enabling flexible control performance.

Voltage Range: Works across 18 V DC to 32 V DC, with a nominal rating of 24 V DC.

Current and Power: Maximum rated current of 165 mA and total power consumption of 3 W.

Integration: Compatible with the AADvance T9892 terminal assembly module for additional output expansion.

FAQ

Q: What is the standard operating voltage of the T8901 module, and does it tolerate voltage fluctuations?
A: Rated at 24 V DC, operating stably from 18 V DC to 32 V DC wide range.

Q: How many channels and what is the maximum power consumption of the T8901 module?
A: It integrates 8 channels with 3 W maximum power consumption (165 mA max current).

Q: What scan times does the T8901 module support for high-speed safety logic?
A: Dual scan rates of 1.174 ms or 2.202 ms.

Q: Will the T8901 module stop working at 20 V DC supply drop?
A: No, 20 V DC is within its 18–32 V DC operating range, so it continues normal operation.

Q: What are the benefits of the low-power design of the T8901 module?
A: It reduces heat buildup, lowers cooling demand, and minimizes thermal aging risk.
