Overview
Place of Origin: |
USA |
Brand Name: |
ICS TRIPLEX |
Model Number: |
T8300C |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Part Number |
T8300C |
|
Part Name |
Expander Processor |
|
Dimensions |
48.3 × 33.8 × 26.5 cm |
|
Weight |
5.9 kg |
|
Supply Voltage |
220 Vac ±15%, 50 Hz |
|
Processor |
32-bit multi-core processor, 1.2 GHz |
|
Communication Interfaces |
2 × RS485; 1 × Ethernet (100 Mbps) |
|
Operating Temperature |
-5°C to +60°C (23°F to 140°F) |
|
Operating Humidity |
5–95% RH (non-condensing) |
|
Protection Rating |
IP20 |
Description
The ICS Triplex T8300C extended processor is a high-performance processing unit designed specifically for industrial automation control systems. It boasts powerful data processing capabilities and stable operating performance, making it suitable for signal extension and processing in various complex industrial environments
Applications
Petrochemical Refineries: Remote I/O cabinet for data preprocessing and Ethernet transmission to control systems.
Thermal Power Plants: Auxiliary cabinet module for stable local power and system coordination.
Coal Gasification Plants: Distributed control node for RS485-based instrument networking.
Steel Plants: Control station module for synchronized multi-channel data handling.
Water Treatment Plants: Distributed gateway for cross-area control and communication.
Common Troubleshooting
Ethernet Communication Loss or Timeout: Check RJ45 connection for looseness and vibration issues. Optimize scan timing to avoid processing congestion.
RS485 Packet Loss or Handshake Failure: Ensure proper shielding grounding and correct 120Ω termination at both bus ends.
Module Failure or Status Light Off: Verify 220V AC input stability. Voltage drops or overloads may trigger protection and require restart.
FAQ
Q1: T8300C 1.2GHz multi-core design vs standard extension modules?
A: Enables local millisecond-level I/O processing and preprocessing, improving real-time system response.
Q2: T8300C under 220V AC ±15%, will 250V damage it?
A: No. Limit is about 253V AC (115% of 220V). 250V is acceptable, but surge protection is recommended.
Q3: T8300C dual RS485 supports different devices?
A: Yes. Two RS485 channels are fully independent with configurable baud rate, node ID, and protocols.
Q4: T8300C operation at -5°C outdoor cabinets?
A: Not guaranteed. Minimum operating temperature is -5°C; heating is required below this level.
Q5: T8300C IP20 cleaning with wet cloth?
A: Not allowed. IP20 is non-liquid protection and includes 220V AC risk; must be powered off and dry cleaned.
