Overview
Siemens · SIMATIC NET CP 1600
6GK1161-6AA00 SIMATIC NET CP 1616 PROFINET Communication Processor
The CP 1616 is a PCI communication processor based on the ERTEC 400 for connecting industrial PCs to PROFINET IO as a controller or device.
At a Glance
| Brand | Siemens |
|---|---|
| Model | 6GK1161-6AA00 |
| Product Type | PCI PROFINET IO communication processor |
| Core Function | Adds deterministic PROFINET IO controller and device communication to an industrial PC |
| Application or Compatible Series | PC-based automation and motion systems requiring a CP 1616 with an integrated real-time Ethernet switch |
Exact Identification
Match 6GK1161-6AA00 character by character and confirm the complete SIMATIC NET CP 1616 PROFINET Communication Processor designation.
Interface Arrangement
Confirm the installed supply, ports, field connections and required accessories before wiring the replacement.
Configuration Check
Preserve the approved engineering project, network parameters and application data used by the installed system.
Product Overview
The CP 1616 is a PCI communication processor based on the ERTEC 400 for connecting industrial PCs to PROFINET IO as a controller or device.
The board offloads real-time IO communication from the host PC. Four RJ45 ports provide switched PROFINET connections. Supported software allows operation as a PROFINET IO controller or device.
Key Functions
PROFINET IO Processing
The board offloads real-time IO communication from the host PC.
Integrated Real-Time Switch
Four RJ45 ports provide switched PROFINET connections.
Flexible Device Roles
Supported software allows operation as a PROFINET IO controller or device.
Official Specifications
| Processor Type | CP 1616 |
|---|---|
| Host Interface | 32-bit PCI, 33/66 MHz |
| PCI Signaling | 3.3 V / 5 V universal key |
| Communication ASIC | ERTEC 400 |
| PROFINET Ports | 4 × RJ45 |
| Ethernet Rate | 100 Mbit/s |
| Integrated Switch | 4-port real-time switch |
| PROFINET IO Controller | Supported |
| PROFINET IO Device | Supported |
| Extended PROFINET Diagnostics | Supported from firmware V2.0 |
| Automatic Device Replacement | Supported from firmware V2.2 |
| Power Source | PCI backplane or approved external DC input |
| Module Format | PCI plug-in card |
| Degree of Protection | IP00 |
| Engineering | NCM PC / supported development kit |
Frequently Asked Questions
Which host slot is required by 6GK1161-6AA00?
Use a compatible 32-bit PCI slot with the supported 3.3 V or 5 V signaling.
How many PROFINET ports are available on 6GK1161-6AA00?
The integrated real-time switch provides four RJ45 interfaces.
Can 6GK1161-6AA00 operate as both controller and device?
Yes; select the required PROFINET IO role in the supported software environment.
Which firmware enables automatic device replacement for 6GK1161-6AA00?
The topology-based replacement function is supported from firmware version 2.2.
What should be saved before replacing 6GK1161-6AA00?
Preserve the PC station configuration, firmware, device name, IP settings, IO mappings and driver version.
Does 6GK1161-6AA00 require a separate Ethernet switch?
Not for four local connections, because a real-time switch is integrated on the board.
What should be tested after installing 6GK1161-6AA00?
Verify PCI recognition, driver operation, every Ethernet port, IO data exchange and real-time diagnostics.
Compatibility & Ordering Notes
Compatibility Checklist
- Use a supported industrial PC, PCI slot and SIMATIC NET software release.
- Match firmware, IO role and PROFINET topology to the saved project.
- Verify all four real-time switch ports after replacement.
