SIMATIC S7-mEC 6ES7677-1DD10-0BA0 EC31 Embedded Controller
SIMATIC S7 modular embedded controller EC31 with Intel Core Duo 1.2 GHz processor and Windows Embedded Standard 2009.
At a Glance
| Manufacturer | Siemens |
|---|---|
| Article Number | 6ES7677-1DD10-0BA0 |
| Product Type | SIMATIC S7-mEC EC31 embedded controller |
| Core Function | Industrial embedded controller with Windows Embedded Standard and SDK interface |
| Application / Compatible Series | S7-mEC systems with S7-300 modules and optional EM PC / EM PCI-104 expansion |
Match the complete article number and installed hardware.
Confirm Ethernet, S7 backplane-bus and USB connections documented for the EC31 platform.
Verify project data and official Siemens documentation.
Product Overview
6ES7677-1DD10-0BA0 is officially identified by Siemens as the EC31 in the SIMATIC S7-mEC family. SIMATIC S7 modular embedded controller EC31 with Intel Core Duo 1.2 GHz processor and Windows Embedded Standard 2009.
For replacement and quotation, compare the complete article number, hardware version, interface requirements and installed configuration.
Key Functions
Model-Specific Configuration
6ES7677-1DD10-0BA0: Intel Core Duo 1.2 GHz processor.
System Interface
6ES7677-1DD10-0BA0: 1 GB RAM and 4 GB integrated flash memory.
Performance & Memory
6ES7677-1DD10-0BA0: Windows Embedded Standard 2009 operating system.
Replacement Control
6ES7677-1DD10-0BA0: 256 KB non-volatile memory for retentive data.
Official Specifications
| Hardware Product Version | 01 |
|---|---|
| Programming Interface | Software Development Kit (SDK EC31) |
| Processor | Intel Core Duo 1.2 GHz |
| Main Memory | 1 GB RAM |
| Integrated Flash Memory | 4 GB |
| Flash Partitioning | C: 2.5 GB; D: 1.5 GB |
| Operating System | Windows Embedded Standard 2009 |
| Retentive Memory | 256 KB non-volatile |
| Supply Voltage | 24 V DC |
| Permissible DC Range | 20.4 to 28.8 V DC |
| Input Current | Typically 0.8 A at 24 V DC, excluding backplane-bus and USB supply |
| Voltage Interruption Backup | 5 ms |
| Power Loss | Typically 20 W, excluding backplane-bus and USB supply |
| Reverse Polarity Protection | Yes |
| Permitted Potential Difference | 75 V DC / 60 V AC to the mounting rail |
| Electrical Isolation | Ethernet isolated from electronic circuits |
| USB Interfaces | 2 x USB 2.0 high-speed, 500 mA |
| PROFINET Interfaces | 2 x 10/100 Mbit/s with RJ45 |
| Fast Ethernet Interface | 1 x 10/100 Mbit/s with RJ45 |
| MMC Slot | 1 |
Frequently Asked Questions
How many S7-300 expansion racks can be connected to 6ES7677-1DD10-0BA0?
The system supports up to four racks with up to eight modules per rack, subject to the documented S7-mEC configuration rules.
Which Ethernet connections are available for commissioning 6ES7677-1DD10-0BA0?
Two 10/100 Mbit/s PROFINET ports and one separate 10/100 Mbit/s Fast Ethernet port are provided, all with RJ45 connectors.
What USB capability is available on 6ES7677-1DD10-0BA0?
Two USB 2.0 high-speed interfaces are provided, each specified for 500 mA.
How are retentive data protected during a short power interruption on 6ES7677-1DD10-0BA0?
The hardware provides 256 KB of non-volatile retentive memory and a 5 ms voltage-interruption bridge.
Which operating system and recovery media are supplied with 6ES7677-1DD10-0BA0?
Windows Embedded Standard 2009 is preinstalled, and the product package includes documentation media and a Restore DVD.
What cabinet environment is required for 6ES7677-1DD10-0BA0?
Use an industrial enclosure suitable for an IP20 device and keep the ambient temperature within 0 to 50 °C.
Which software interface is used to program hardware functions on 6ES7677-1DD10-0BA0?
Use the SDK EC31; the RUN/STOP switch and LED functions can be accessed through the documented software interface.
Compatibility & Ordering Notes
Compatibility Checklist for 6ES7677-1DD10-0BA0
Match the full suffix without shortening the order number.
Confirm the installed SIMATIC S7-mEC hardware and project version.
Verify Ethernet, S7 backplane-bus and USB connections documented for the EC31 platform.
Confirm required memory media, connectors and accessories in the written quotation.
