6ES7315-2AG10-0AB0 SIMATIC S7-300 CPU 315-2 DP
The CPU 315-2 DP is an S7-300 controller with 128 KB of work memory, an integrated MPI interface and a second PROFIBUS DP master/slave interface.
At a Glance
| Brand | Siemens |
|---|---|
| Model | 6ES7315-2AG10-0AB0 |
| Product Type | Programmable logic controller CPU with MPI and PROFIBUS DP |
| Core Function | Runs S7-300 control programs and manages distributed PROFIBUS DP devices |
| Application or Compatible Series | Legacy SIMATIC S7-300 stations requiring a CPU 315-2 DP with 128 KB work memory |
Exact Identification
Match 6ES7315-2AG10-0AB0 character by character and confirm the complete SIMATIC S7-300 CPU 315-2 DP designation.
Interface Arrangement
Confirm the installed supply, ports, field connections and required accessories before wiring the replacement.
Configuration Check
Preserve the approved engineering project, network parameters and application data used by the installed system.
Product Overview
The CPU 315-2 DP is an S7-300 controller with 128 KB of work memory, an integrated MPI interface and a second PROFIBUS DP master/slave interface.
The second interface connects distributed PROFIBUS devices in master or slave operation. The controller provides the documented 128 KB memory and instruction performance. A removable SIMATIC MMC carries load memory and the user project.
Key Functions
Integrated DP Master/Slave
The second interface connects distributed PROFIBUS devices in master or slave operation.
S7-300 Processing
The controller provides the documented 128 KB memory and instruction performance.
Micro Memory Card Storage
A removable SIMATIC MMC carries load memory and the user project.
Official Specifications
| CPU Type | CPU 315-2 DP |
|---|---|
| Integrated Work Memory | 128 KB |
| Firmware Generation | V2.0 |
| Integrated Interface 1 | MPI |
| Integrated Interface 2 | PROFIBUS DP master/slave |
| Maximum DP Rate | 12 Mbit/s |
| Rated Supply | 24 V DC |
| Micro Memory Card | Required |
| Firmware Update Card | 4 MB or larger for updates from early firmware |
| Binary Instruction Reference | 0.1 ms per 1,000 instructions |
| Engineering Software | STEP 7 V5.2 or later for the documented platform |
| Process Image Reference | 128 bytes inputs / 128 bytes outputs |
| Controller Platform | SIMATIC S7-300 |
| Distributed I/O | PROFIBUS DP |
Frequently Asked Questions
Which fieldbus role is available on 6ES7315-2AG10-0AB0?
The second interface can be configured as a PROFIBUS DP master or slave.
How much work memory is integrated in 6ES7315-2AG10-0AB0?
The CPU provides 128 KB of work memory.
Does 6ES7315-2AG10-0AB0 need a Micro Memory Card?
Yes; use an approved SIMATIC MMC for load memory and project storage.
Which supply is required by 6ES7315-2AG10-0AB0?
Provide a stable 24 V DC supply within the S7-300 installation limits.
What must be backed up before replacing 6ES7315-2AG10-0AB0?
Preserve the STEP 7 project, MMC contents, MPI address, DP configuration and communication connections.
Can firmware be updated online from every revision of 6ES7315-2AG10-0AB0?
No; early firmware requires the documented memory-card update procedure and a card of sufficient capacity.
What should be checked after installing 6ES7315-2AG10-0AB0?
Verify CPU startup, MPI access, DP master or slave operation, distributed I/O and diagnostics.
Compatibility & Ordering Notes
Compatibility Checklist
- Use the matching CPU generation and STEP 7 hardware catalog entry.
- Preserve the MMC, MPI parameters and complete PROFIBUS configuration.
- Confirm firmware-update prerequisites before changing revisions.
