Overview
Place of Origin: |
Sweden |
Brand Name: |
ABB |
Model Number: |
SDCS-IOB-3 3BSE004086R1 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
SDCS-IOB-3 3BSE004086R1 |
|
Product Type |
I/O Connection Board |
|
Dimensions |
23.3 x 9 x 3 cm |
|
Weight |
0.2 kg |
|
Supply Voltage |
230 V |
|
Current Rating |
1 A |
|
Communication Interface |
Modbus TCP/IP |
|
I/O Channels |
16 Input / 16 Output |
|
Operating Temperature |
-20°C to +70°C |
|
Storage Temperature |
-40°C to +85°C |
|
Protection Rating |
IP20 |
Description
The ABB SDCS-IOB-3 3BSE004086R1 is a high-performance I/O connection board designed for integration into ABB automation systems. This device acts as a crucial interface between field devices and the central processing unit (CPU), facilitating real-time interaction. By providing connection points for both digital and analog input/output (I/O) signals, the board ensures smooth and reliable communication within the automation system.
Applications
Aluminum processing plant: Used for synchronous signal connection of extruders and cutting machines.
Cement production plant: Responsible for logic signal exchange between the elevator and feeding system.
Plastics product plant: Integrated into the control link between the injection molding machine drive system and the external safety barrier.
Water treatment plant: Used for remote start/stop and fault feedback of variable frequency pump sets.
Fertilizer production plant: Suitable for data interface between the conveyor belt weighing system and the control room.
Competitive Advantage
Efficient Connectivity: Facilitates smooth communication between field devices and CPU.
Versatile Input/Output: Supports both digital and analog I/O for diverse applications.
Space-Saving Design: Compact and durable, designed for industrial use.
Reliable Performance: Built to provide consistent and stable real-time interaction.
FAQ
Q1: What is the SDCS-IOB-3 3BSE004086R1?
A1: It is an I/O Connection Board.
Q2: Is a 1A current rating sufficient for SDCS-IOB-3 3BSE004086R1?
A2: It is perfectly adequate for standard control signals and small relay drives. For driving high-power contactors, it is recommended to add a repeater.
Q3: How do I set the Modbus TCP/IP address on SDCS-IOB-3 3BSE004086R1?
A3: Network parameters are usually assigned via onboard DIP switches or accompanying software tools.
Q4: Can SDCS-IOB-3 3BSE004086R1 operate in an environment of -40°C?
A4: No. Its storage temperature supports -40°C, but the operating ambient temperature should be kept above -20°C.
Q5: Does 230V in SDCS-IOB-3 3BSE004086R1 refer to the supply voltage or the signal voltage?
A5: This parameter usually refers to the logic level height supported by the I/O channels. The board's own system power supply usually still requires a DC input.
