Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
MC-TSIM12 51303932-476 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model: |
MC-TSIM12 51303932-476 |
|
Product Type: |
Serial Interface Module |
|
Dimensions: |
15.2 × 12 × 8.2 cm |
|
Weight: |
0.3 kg |
|
Color: |
Industrial grey |
|
Serial Input Channels: |
2 |
|
Interface Types: |
RS-232; RS-422; RS-485 (EIA-232/422/485) |
|
Network Speed: |
19.2 kbps |
|
Mounting Type: |
Panel mount |
|
Conformal Coating: |
Yes |
|
CE Compliance: |
Yes |
|
Redundancy Support: |
Not supported |
Description
Honeywell MC-TSIM12 51303932-476 is a Serial Interface Module used to facilitate communication between Honeywell's Distributed Control Systems (DCS) and external serial devices using the Modbus RTU protocol. It supports both EIA-232 (RS-232) and EIA-422/485 (RS-422/485) interfaces, providing flexibility for various industrial applications.
Applications
Gas compression station: Connects RTU and flow computers, enabling stable serial data transmission to control center.
Chemical plant: Links smart scales and analyzers for reliable process data transfer under corrosion protection.
Metallurgy plant: Collects data from furnaces and inverters, ensuring stable communication in high-EMI environments.
Wastewater plant: Connects water quality instruments and PLCs via RS-485 for long-distance monitoring.
Rail transit power system: Communicates with protection relays and UPS systems for stable serial data exchange.
Troubleshooting Common Problems
Communication Interruption or Packet Loss: Check if the field wiring matches the selected mode (RS-232/422/485), and test if the baud rate setting at 19.2 kbps is completely consistent with the host computer.
Signal Attenuation or No Response: For long-distance multi-machine communication using RS-485, verify that a matching terminating resistor is connected at the end, and confirm that there are no external wiring short circuits on the two input channels.
FAQ
Q: How many serial input channels does MC-TSIM12 51303932-476 have?
A: This model has 2 serial input channels.
Q: What interface types does MC-TSIM12 51303932-476 support?
A: It supports RS-232, RS-422, and RS-485 (EIA-232/422/485).
Q: What is the network transmission rate of MC-TSIM12 51303932-476?
A: Its network speed is 19.2 kbps.
Q: What mounting method does MC-TSIM12 51303932-476 use?
A: This model uses panel mount installation.
Q: What is the exterior color of MC-TSIM12 51303932-476?
A: Its color is Industrial Grey.
