DS200FSAAG2A Field Supply Gate Amplifier Board

Overview

Place of Origin:	USA
Brand Name:	GE
Model Number:	DS200FSAAG2A
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Description

DS200FSAAG2A is a Field Supply Gate Amplifier Board manufactured and designed by General Electric as part of the Mark V Series used in GE Drive Control systems. There are 5 jumpers, a 10-pin connector, 2 fuses, and more on the GE Field Supply Amplifier Board. It is also filled with a variety of test points. A 10-pin terminal connector is present. It has parts that take in a signal and amplify it by sending it through a transistor, integrated circuit (IC), or tube that combines it with more current from a power source. The external field exciter modules include incoming line fuses, metal-oxide varistor (MOV) voltage suppressors, AC and DC line filters, a thyristor bridge, and a DS200FSAA Field Supply Gate Amplifier Board (FSAA). The FEAN module also includes a cooling fan.

Applications

Industrial Control

Motor control

Lighting control

HVAC control

FEATURES

Field power is supplied through fuses on the SDCIG1 board or the external field exciter module. A thyristor diode bridge (on the SDCIG1) or thyristor bridge (in the external field exciter module) controls the field current.The SDCI or DCFB decodes Held Ering signals from the SDCC to direct firing pulses to gate pulse transformer drivers for the thyristors in the bridge.

The field power is applied through a shunt. A voltage-controlled oscillator (VCO) circuit on the SDCI or DCFB board converts the voltage across the shunt into a frequency signal representing field current. The frequency signal is sent to the SDCC card, which controls the phase angle of the thyristor firing.

The SCR power conversion bridge receives 3-phase power. G, C, and C Extension (CX) frame drives include fuses FU1, FU2, and FU3 on the incoming ac power lines J, K, L, and M frame drives include fuses FU1 through FUI2 on the deleg lines

The SCR bridge is made up of SCR modules, sized for the drive's current rating.The hardware drawings and elementary diagrams included in the appendices show the SCR bridges for each frame size

Advantages

Compact size, saves space

Simple installation and easy operation

Reliable performance and stable operation

Affordable price, high cost performance

FREQUENTLY ASKED QUESTIONS

What is a DS200FSAAG2A Field Supply Gate Amplifier Board?

A Field Supply Gate Amplifier Board is an electronic component used in industrial systems, particularly in turbine control or power electronics, to regulate and amplify signals for field excitation. It helps control the operation of large motors or generators by ensuring precise field current and voltage management.

How does a DS200FSAAG2A Field Supply Gate Amplifier Board work?

The board works by receiving input signals from the control system, processing them, and regulating the field supply to maintain desired excitation. It amplifies gate signals for switching devices like thyristors or IGBTs in the field circuit.

What are the typical applications of a DS200FSAAG2A Field Supply Gate Amplifier Board?

This board is used in turbine control systems, motor drives, and generator excitation systems to regulate field voltage and maintain operational stability.

Is this product brand new?

Yes, DS200FSAAG2A is brand new, original, unused, and factory sealed

Do you have it in stock?

Yes, right now we have DS200FSAAG2A in stock ready for shipment, we can support video inspection.
