Overview
AS3100S2-Z2 Accelerometer
At a Glance
Place of Origin: |
USA |
Brand Name: |
Bently Nevada |
Model Number: |
AS3100S2-Z2 |
Minimum Order Quantity: |
1 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Product Overview
Description
The AS3100S2-Z2 Integrated Electronics Piezo-Electric (IEPE) Accelerometer is specifically engineered for high-precision vibration monitoring in demanding industrial environments. Featuring a rugged stainless steel casing (28 × 9.2 × 7.5 cm) with a lightweight design of only 0.14 kg, this accelerometer combines durability with ease of installation in confined spaces. Its side-exit sensor cable ensures flexible connectivity, while the piezoelectric sensing element provides a wide frequency range of 0.5–10,000 Hz, high linearity with only 1% amplitude nonlinearity, and a peak acceleration capacity of 80 g. Integrated amplification enables the device to produce a stable output voltage proportional to acceleration, ensuring immunity to electrical noise and compatibility with a wide range of condition monitoring systems. With a sensitivity of 100 mV/g ±5% at 25°C, a resonant frequency of 22 kHz, and robust protection against temperature extremes from -55°C to +120°C, the AS3100S2-Z2 excels in both continuous monitoring and dynamic measurement applications. Designed with hazardous area certification (Zone 2 rated), EMI/RFI shielding, ESD protection, and reverse wiring safeguards, it is ideal for harsh industrial settings where reliability, accuracy, and safety are paramount.
Key Functions
Applications
1. Rotating Machinery Vibration Monitoring
Ideal for turbines, compressors, and motors, the AS3100S2-Z2 detects vibration patterns up to 10,000 Hz, ensuring early fault detection and predictive maintenance in critical industrial equipment.
2. Harsh Environment Industrial Automation
With a temperature tolerance from -55°C to +120°C and hermetic sealing, it can reliably operate in chemical plants, refineries, and outdoor automation installations.
3. Condition-Based Maintenance Programs
The high sensitivity of 100 mV/g and low electrical noise allow for accurate continuous monitoring in walk-around inspection programs and permanent installations, reducing downtime and maintenance costs.
4. Hazardous Area Equipment Monitoring
Zone 2 hazardous area rating ensures safe use in environments with flammable gases or dust, enabling vibration monitoring on pumps, fans, and process equipment in compliance with safety regulations.
5. High-Speed Rotating Equipment Diagnostics
The 22 kHz resonant frequency allows capturing high-frequency signals from high-speed rotors and gearboxes, supporting root-cause analysis and early fault detection.
Official Specifications
Quick Detail
|
Cable Exit: |
Side Exit Sensor |
|
Sensitivity: |
100 mV/g |
|
Acceleration Range: |
80 g |
|
Frequency Range (3 dB): |
0.5–10,000 Hz |
|
Hazardous Area Rating: |
Zone 2 Rated |
|
Dimension: |
28x9.2x7.5cm |
|
Weight: |
0.14 kg |
Specifications
|
Sensitivity: |
±5% @ 25°C, 100 mV/g |
|
Acceleration Range: |
80 g peak |
|
Amplitude Nonlinearity: |
1% |
|
Resonant Frequency: |
22 kHz |
|
Transverse Sensitivity: |
Max ±5% of axial |
|
Temperature Response: |
-55°C: -20%, +120°C: +10% |
|
Voltage Source: |
18–30 Vdc |
|
Current Regulating Diode: |
2–10 mA |
|
Broadband Electrical Noise: |
2.5 Hz–25 kHz: 700 μg |
|
Spectral Electrical Noise @ 10 Hz: |
10 μg/√Hz |
|
Spectral Electrical Noise @ 100 Hz: |
5 μg/√Hz |
|
Spectral Electrical Noise @ 1000 Hz: |
5 μg/√Hz |
|
Output Impedance, Max: |
100 Ω |
|
Bias Output Voltage: |
12 Vdc |
|
Grounding: |
Case isolated, internally shielded |
|
Temperature Range: |
-55°C to 120°C |
|
Vibration Limit: |
500 g peak |
|
Shock Limit: |
5,000 g peak |
Frequently Asked Questions
What is the model number?
The listed model number is AS3100S2-Z2.
What is the brand name?
The listed brand name is Bently Nevada.
What is the place of origin?
The listed place of origin is USA.
What are the packaging details?
The listed packaging details are Original new Factory Sealed.
What is the delivery time?
The listed delivery time is 5-7 days.
Is this model available?
The listed supply status is In stock.
What are the payment terms?
The listed payment terms are T/T.
Compatibility & Ordering Notes
Competitive Advantage
1. Rugged Stainless Steel Design
Corrosion-resistant stainless steel housing withstands harsh conditions, extending service life and reducing replacement frequency.
2. Hermetically Sealed and Case Isolated
Prevents moisture ingress and electrical interference, ensuring consistent output voltage and reliable measurements even in wet or electrically noisy environments.
3. EMI/RFI and ESD Protection
Integrated shielding reduces susceptibility to electrical noise and transient spikes, preserving signal integrity for accurate condition monitoring.
4. Reverse Wiring and Ground Loop Immunity
Cross-wiring or improper grounding will not damage the sensor, allowing easier installation and safer operation in permanent mount applications.
5. Lightweight and Compact Form Factor
Weighing only 0.14 kg with compact dimensions, the sensor can be mounted in tight spaces and used in portable inspection programs without compromising sensitivity or durability.
