Overview
AMS 6500 ATG MACHINERY PROTECTION
A6500-UM Universal Measurement Card
Official-source product identification, application guidance and ordering checks for A6500-UM.
At a Glance
| Brand | Emerson (AMS/EPRO) |
|---|---|
| Model | A6500-UM |
| Product Type | Universal Measurement Card |
| Core Function | Configurable machinery-protection measurement across vibration, position, expansion and speed modes. |
| Application / Compatible Series | AMS 6500 ATG machinery protection |
Verified identification
A6500-UM is identified by the complete manufacturer model and the photographed unit.
Application focus
A6500-UM is intended for configurable machinery-protection measurement across vibration, position, expansion and speed modes.
Ordering control
A6500-UM should be matched by the full nameplate, hardware revision and installed configuration.
Product Overview
Emerson A6500-UM is a two-channel universal measurement card for the AMS 6500 ATG machinery protection system.
The official data sheet supports eddy-current, piezoelectric, seismic, low-frequency, Hall-effect, LVDT and dynamic-pressure inputs, together with five digital inputs, six digital outputs and isolated 0/4–20 mA outputs. Measurement mode and sensor conditioning must be configured correctly.
Key Functions
Universal Sensor Inputs
Accepts two independent or combined channels for several common machinery-protection sensor technologies.
Measurement and Alarm Processing
Performs configured vibration, position, speed, key and dynamic-pressure measurements with associated alarm logic.
Rack and Communications Integration
Operates in the A6500-xR rack and transfers results through the internal RS-485 path to the A6500-CC communication card.
Official Specifications
| Measurement channels | 2 independent or combined |
|---|---|
| Digital I/O | 5 digital inputs; 6 solid-state outputs |
| Rack format | 3U, 6HP, one slot |
| Analog outputs | Isolated 0/4–20 mA outputs |
| Operating temperature | −20 to +70 °C |
| Universal Sensor Inputs | Accepts two independent or combined channels for several common machinery-protection sensor technologies. |
| Measurement and Alarm Processing | Performs configured vibration, position, speed, key and dynamic-pressure measurements with associated alarm logic. |
| Rack and Communications Integration | Operates in the A6500-xR rack and transfers results through the internal RS-485 path to the A6500-CC communication card. |
| RS-485 Support | Supported |
| Operating Temperature Range | 20 to +70 °C |
| Measurement Principle | Eddy current |
| Minimum Operating Temperature | −20 °C |
| Maximum Operating Temperature | +70 °C |
| Current Output Range | 0/4–20 mA |
Official source: Emerson A6500-UM Universal Measurement Card Specifications Sheet. Commercial stock, warranty and shipping statements are seller terms.
Frequently Asked Questions
Where does A6500-UM fit within an AMS 6500 ATG machinery protection architecture?
It is intended for AMS 6500 ATG machinery protection.
What customer application is addressed by the A6500-UM Universal Measurement Card?
Configurable machinery-protection measurement across vibration, position, expansion and speed modes.
What rack, terminal and field-wiring checks are required before installing A6500-UM?
Record both channel modes, sensors and scaling values. Review digital I/O, analog outputs and alarm logic.
Why is universal sensor inputs important when integrating A6500-UM?
Accepts two independent or combined channels for several common machinery-protection sensor technologies.
What documented measurement and alarm processing limits apply to A6500-UM?
Performs configured vibration, position, speed, key and dynamic-pressure measurements with associated alarm logic.
How should rack and communications integration be checked during maintenance of A6500-UM?
Operates in the A6500-xR rack and transfers results through the internal RS-485 path to the A6500-CC communication card.
Which configuration and hardware revision checks are required when ordering A6500-UM?
The unit should be matched by the full nameplate, hardware revision and installed configuration.
Compatibility & Ordering Notes
Compatibility checklist for A6500-UM
- Confirm the A6500-UM model and supported A6500-xR rack.
- Record both channel modes, sensors and scaling values.
- Review digital I/O, analog outputs and alarm logic.
- Verify A6500-CC communication and configuration backup.
