Overview
Place of Origin: |
USA |
Brand Name: |
Woodward |
Model Number: |
5464-013 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
5464-013 |
|
Product Type |
Semi Insulated Input Driver |
|
Series |
NETCON 5000 |
|
Dimensions |
2.6 × 24.8 × 26.2 cm |
|
Weight |
0.92 kg |
|
Input Voltage |
24 VDC |
|
Current Consumption |
30 mA per channel |
|
Fault Indicator |
Red LED for fault |
|
Mounting Type |
Panel mount |
|
Operating Temperature |
-40°C to +85°C |
|
Storage Temperature |
-50°C to +100°C |
|
Humidity Range |
5%–95% RH (non-condensing) |
Description
The 5464-013 is a semi insulated input driver from the NetCon 5000 series manufactured by Woodward. The 5464-013 converts signals for the CPU of the system to understand and use.In addition, the 5464-013 can be used with the other NetCon 5000 modules.
Applications
Power plants: drive turbine hydraulic control valves, servos, and dampers.
Chemical plants: command electric actuators and pneumatic control valves for material transfer.
Refineries: regulate oil pumps, recycle valves, and pipeline pressure valves.
Steel plants: control blast furnace feeders, rolling mill servos, and cooling pump valves.
Pulp and paper plants: drive pulp flow valves, coating pressure valves, and dryer dampers.
Troubleshooting
Red LED fault indicator on panel:
This indicates built-in hardware diagnostics have detected an issue. First check the external wiring for short circuit, open circuit, or insulation leakage to ground. Since the module is semi-isolated, ensure stable reference potential between external supply and internal circuit to avoid abnormal current backflow.
Single-channel signal loss or NO/NC lockout:
Measure loop current with a multimeter to verify whether it reaches the nominal 30 mA level. If below threshold, it is usually caused by oxidized switch contacts increasing resistance. Clean contacts using appropriate electronic contact cleaner to restore normal operation.
FAQ
Q: What DC input voltage is required for the 5464-013?
A: Input voltage is 24 VDC.
Q: What is the current consumption per channel of the 5464-013?
A: Consumption is 30 mA per channel.
Q: What color LED indicates a fault on the 5464-013?
A: Red LED lights up during a fault.
Q: What mounting method does the 5464-013 use?
A: Uses panel mount installation.
Q: What is the storage temperature range of the 5464-013?
A: Storage temperature range is -50°C to +100°C.
