Overview
Place of Origin: |
USA |
Brand Name: |
Woodward |
Model Number: |
5460-667 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
5460-667 |
|
Product Type |
Power Supply Module |
|
Dimensions |
12.5 × 22 × 17.1 cm |
|
Weight |
1.76 kg |
|
Input Voltage |
125 VDC |
|
Chassis Compatibility |
Woodward MicroNet Simplex, MicroNet Plus, MicroNet TMR systems |
|
Cooling & Ventilation |
Combined natural convection and chassis forced-air circulation |
|
Operating Temperature |
-40°C to +70°C |
|
Storage Temperature |
-45°C to +85°C |
|
Humidity Range |
5%–95% RH (non-condensing) |
Description
The Woodward 5460-667 is a power supply module for Woodward's classic high-performance turbine control architectures. This module provides stable power to various electronic components within the control system. It receives external electrical input, converts the voltage, and adjusts it to the values required by the hardware.
Applications
Large Thermal Power Plants: Plugged into MicroNet TMR redundant power slots, supplying reliable DC power for turbine DEH control systems.
Gas Turbine Plants: Installed near turbine control rooms, designed to withstand high internal cabinet heat in harsh operating conditions.
Offshore Drilling Platforms: Stable power supply in high humidity and salt spray environments using forced-air cooling systems.
Nuclear Power Plants: Acts as a core DC power unit for MicroNet governor systems with long-term stable output.
Coalbed Methane Processing Plants: Provides protected, shielded power supply for explosion-proof control cabinets, reducing voltage fluctuations from heavy loads.
Troubleshooting
Power fault, no output: Check 125 Vdc input polarity and voltage; if normal, inspect backplane connectors for damage or short.
Rack over-temperature alarm: Check airflow blockage and clean dust filters; ensure forced cooling is effective.
High DC ripple: Likely capacitor aging from high temperature; measure ripple with oscilloscope and replace module if needed.
FAQ
Q: What DC input voltage is required for 5460-667?
A: The input voltage is 125 VDC.
Q: Which chassis systems does 5460-667 support for interconnection?
A: It supports Woodward MicroNet Simplex, MicroNet Plus, and MicroNet TMR systems.
Q: What cooling and ventilation method does 5460-667 use?
A: It uses natural convection combined with forced air circulation in the chassis.
Q: What is the operating temperature range of 5460-667?
A: The operating temperature range is -40°C to +70°C.
Q: What is the storage temperature range of 5460-667?
A: The storage temperature range is -45°C to +85°C.
