Overview
Place of Origin: |
USA |
Brand Name: |
Woodward |
Model Number: |
5417-040 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
5417-040 |
|
Product Type |
MicroNet Low Density Analog Cable |
|
Dimensions |
34 × 30 × 4 cm |
|
Weight |
0.7 kg |
|
Length |
10 ft |
|
Color |
Gray |
|
Connector Type |
37-pin male to female |
|
System Compatibility |
Woodward MicroNet™ / NetCon® systems |
|
Signal Type |
Low Density Analog |
|
Shielding Style |
MicroNet style |
Description
The Woodward 5417-040 is a MicroNet low-density analog cable. This cable is used to connect control components and terminal blocks within a control enclosure. It transmits low-density analog electrical signals between isolated electrical components, allowing hardware devices in different locations to exchange data.
Applications
Gas Turbine Power Plants: Transmits key analog signals like bearing temperature and vibration to MicroNet control systems.
Large Compressor Plants: Provides low-loss analog pressure data for anti-surge control in heavy compressor cabinets.
Steel Metallurgy Blast Furnace Plants: MicroNet shielded design prevents damage and shutdowns in high-temperature dusty environments.
Petrochemical Hydrogen Plants: Connects SIS systems and valve positioners using stable 4–20mA analog signals.
Hydropower Stations: Transfers turbine governor and oil pressure signals to central control systems via high-grade shielding.
Troubleshooting
Multi-channel analog signal skipping/distortion: 37-pin connector misalignment or dust can cause poor contact. Power off, unplug, and clean both ends with contact cleaner; check pin alignment.
External interference/data errors: AIN board EMI may be caused by cable twisting or sharp bends damaging MicroNet shielding. Replace cable if needed.
Connector not locking: 37-pin D-sub screws may loosen under vibration, causing intermittent faults. Tighten regularly and use anti-vibration washers.
FAQ
Q: What is the cable length of 5417-040 in feet?
A: The cable length is 10 feet.
Q: What is the color of 5417-040?
A: The color is gray.
Q: What type of connector does 5417-040 use?
A: It uses a 37-pin male-to-female connector.
Q: Which systems does 5417-040 support for interconnection?
A: It supports interconnection with Woodward MicroNet™ and NetCon® systems.
Q: What type of analog signal does 5417-040 transmit?
A: It transmits low-density analog signals.
