Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
51401583-200 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
51401583-200 |
|
Product Type |
Network Gateway Interface Board |
|
Dimensions |
36.4 x 36.6 x 1.5 cm |
|
Weight |
0.74 kg |
|
File Transfer Rate |
Up to 12000 words/sec (synchronous execution) |
|
Parameter Throughput |
Up to 1200 points/sec |
|
Communication Standard |
IEEE 802.4 |
|
Rated Operating Voltage |
24 V DC |
|
Operating Voltage Range |
Up to 30 V DC |
|
Channel Isolation Protection |
1500 V DC |
|
Operating Temperature Range |
–40 °C to +70 °C |
|
Storage Temperature Range |
–50 °C to +100 °C |
|
Environmental Compliance |
CE certified |
|
Base Data Transmission Rate |
Up to 9.6 kbps |
|
Supported Network Types (Gateway) |
Carrier Band Network; Fiber Optic Star Network |
Description
The 51401583-200 Network Gateway Interface Board is an industrial communication interface module used to enable data exchange between multiple Local Control Networks within distributed control system architectures. It allows different control domains to communicate and share process information across separated automation networks.
Applications
Petrochemical Refining: Distributed bus data exchange.
LNG Plants: Remote control center communication.
Chemical Plants: Multi-unit data integration and scheduling.
Power Plants: Main control and unit network communication.
Steel Plants: Blast furnace and plant network interconnection.
Troubleshooting
Upper-Lower Network Disconnection: Check IEEE 802.4 cables, connectors, taps, and impedance deviation.
Throughput Drop/Data Stall: Check node limit, broadcast storm, or token/address conflicts if 1200 test points/second not reached.
File Sync Failure/Data Corruption: Verify firmware compatibility when transferring up to 12000 characters/second.
FAQ
Q: What is the file transfer rate of 51401583-200 during synchronous execution?
A: Up to 12000 words per second.
Q: What is the channel isolation protection voltage of 51401583-200?
A: 1500 V DC.
Q: What is the basic data transmission rate of 51401583-200?
A: Up to 9.6 kbps.
Q: What network types does 51401583-200 support as a gateway?
A: Carrier-band networks and fiber-optic star networks.
Q: What is the storage temperature range of 51401583-200?
A: -50°C to +100°C.
