Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
51307038-100 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
51307038-100 |
|
Product Type |
Power Control Module Assembly |
|
Dimensions |
15 x 12 x 7.5 cm |
|
Weight |
0.7 kg |
|
Maximum Level 1 Connections |
8 (ENIM or EHPM) |
|
Minimum CF9 Requirement |
2 (paired) |
|
Data Throughput Speed |
100 Mbps (100Base-T) |
|
Mounting Location |
HPM cabinets only (Class 1 Div 2 approved) |
|
Operating Temperature Range |
-40 °C to +85 °C |
|
Electrical Rating |
250 VAC, 5 A |
|
Media Compatibility |
Air; water; oil (selection dependent) |
Description
The Honeywell 51307038-100 is a Power Control Module Assembly. This module is primarily used to distribute and manage electrical energy to various cards within a control system, maintaining normal power supply to the entire control cabinet. In industrial automation production, it receives external DC input, processes it through internal circuitry, and converts it into stable electrical energy to supply adjacent network modules, interface cards, and mounting bases.
Applications
Power Plants: Ensure continuous power for control CPU and I/O racks.
Petrochemical Plants: Keep SIS running under unstable grid conditions.
Steel Plants: Stabilize automation under high-voltage fluctuations.
Pharmaceutical Plants: Prevent batch loss from sudden power failure.
Nonferrous Smelters: Secure power supply for smelting control systems.
Troubleshooting
Level 1 network packet loss: Check 100 Base T cable for EMI interference; ensure ENIM/EHPM count does not exceed 8.
CF9 cascading/init failure: Verify CF9 units are installed in pairs; single or damaged unit causes self-test failure.
Explosion-proof certification risk: Must remain in HPM cabinets; non-rated installation voids Class 1 Div 2 compliance.
FAQ
Q: What is the maximum Level 1 connection count of 51307038-100?
A: The maximum allowed Level 1 connections are 8 (ENIM or EHPM).
Q: What is the data throughput of 51307038-100?
A: It supports up to 100 Mbps (100Base-T).
Q: Where must 51307038-100 be installed?
A: It must be installed only in Class 1 Div 2 certified HPM cabinets.
Q: What is the operating temperature range of 51307038-100?
A: The operating ambient temperature range is -40°C to +85°C.
Q: What are the electrical ratings of 51307038-100?
A: The electrical rating is 250 VAC, 5 A.
