Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
51304584-100 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Model |
51304584-100 |
|
Product Type |
EPDGP I/O Board |
|
Dimensions |
7.5 x 7.5 x 2 cm |
|
Weight |
0.1 kg |
|
System Compatibility |
TDC 3000 |
|
Use |
EPDG / EPDG2 Peripheral Interface |
|
Operating Temperature Range |
-40 °C to +85 °C |
|
Storage Temperature Range |
-40 °C to +105 °C |
|
Power Consumption |
Max. 10 W |
|
Communication Interface |
RS-485 |
|
Protocol Compatibility |
Modbus RTU |
|
Environmental Compliance |
RoHS compliant |
|
Certification |
CE certified |
Description
The 51304584-100 EPDGP I/O Board is an industrial interface module used in process control operator stations to manage communication between the workstation and multiple peripheral devices. In industrial automation environments, this type of I/O board is used to support human–machine interface (HMI) operations, ensuring stable data exchange between control stations and peripheral devices.
Applications
Chemical Plants: Handle safety instrument signals from transformers and isolators.
Power Plants: Collect turbine protection and generator excitation data.
Steel Plants: Transfer key temperature data from blast furnace and converter systems.
Glass Plants: Monitor multi-channel thermal and pressure signals in furnace lines.
Cement Plants: Link kiln control systems with fan drive inverters.
Troubleshooting
Peripheral Interface Communication Failure: Check RS-485 wiring, Modbus RTU address and baud rate consistency.
Abnormal Power Consumption and Overheating: If power exceeds 10W, shut down and check for overcurrent or short circuit on pins.
Intermittent System Recognition Failure: Check slot oxidation; clean gold fingers and reseat device.
Key Limitations of Hardware Revision G
During routine inspections of the TDC 3000, if your operator station is configured with an earlier external data backup device (such as a Zip drive or Bernoulli disk), the physical hardware version of the card must be Rev G or higher to fully activate the file read/write logic.
FAQ
Q: What is the operating temperature range of 51304584-100?
A: The operating ambient temperature range is -40°C to +85°C.
Q: What is the maximum operating power consumption of 51304584-100?
A: Its power consumption does not exceed 10 W.
Q: What communication interface does 51304584-100 use?
A: It uses an RS-485 communication interface.
Q: What communication protocol does 51304584-100 support?
A: It supports the Modbus RTU protocol.
Q: Which standards does 51304584-100 comply with?
A: It complies with RoHS directive and is CE certified.
