Overview
Place of Origin: |
USA |
Brand Name: |
Bently Nevada |
Model Number: |
330850-50-05 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Quick Detail
|
Total Length and Mounting Option : |
5.0 metres (16.4 feet) system length, panel mount |
|
Agency Approval Option: |
Multiple Approvals |
|
Dimension: |
7.8x6.2x6.5cm |
|
Weight: |
0.22kg |
Description
The 330850-50-05 3300 XL 25 mm Proximitor Sensor is a panel-mount eddy-current signal conditioner designed for turbine monitoring and automated control systems. The 330850-50-05 3300 XL 25 mm Proximitor Sensor accepts one non-contacting 25 mm probe with extension cable and converts axial rotor displacement into a 0.787 V/mm output across a 12.7 mm linear range. Operating on −17.5 to −26 Vdc at 12 mA with a 50 Ω output, the 330850-50-05 3300 XL 25 mm Proximitor Sensor transmits accurate readings to DCS, PLC, or vibration monitoring systems. Its A380 aluminum housing supports operation from −51°C to +100°C and tolerates 100% condensing humidity when connectors are protected. Multiple agency approvals allow the 330850-50-05 3300 XL 25 mm Proximitor Sensor to be used in automated turbine and generator control loops worldwide. Low supply sensitivity (<2 mV/V) ensures precise voltage output even under DC power variations, enabling continuous measurement of differential expansion and real-time rotor movement verification during startup, shutdown, or load changes.
Applications
Measure differential expansion on steam turbines
The 330850-50-05 3300 XL 25 mm Proximitor Sensor monitors rotor-to-casing axial movement using its 12.7 mm linear range and 0.787 V/mm output. Its A380 aluminum housing allows installation close to turbine rotors, providing precise differential expansion measurements during startup, load changes, or shutdown sequences.
Track generator shaft position
The 330850-50-05 3300 XL 25 mm Proximitor Sensor transmits real-time axial displacement signals to DCS or PLC systems. Its low supply sensitivity (<2 mV/V) ensures accurate rotor position tracking for automated control during rotational speed ramps.
Monitor compressor rotor collars or ramps
The 330850-50-05 3300 XL 25 mm Proximitor Sensor operates in temperatures from −51°C to +100°C and 100% condensing humidity, making it suitable for continuous measurement of axial shaft movement on high-speed compressor rotors.
Specifications
|
Proximitor Sensor Input: |
Accepts one noncontacting 3300 XL 25 mm Proximity Probe and Extension Cable. |
|
Power: |
Requires -17.5 Vdc to -26 Vdc without barriers at 12 mA maximum consumption, -23 Vdc to -26 Vdc with barriers. Operation at a more positive voltage than -23.5 Vdc can result in reduced linear range. |
|
Supply Sensitivity: |
Less than 2 mV change in output voltage per volt change in input voltage. |
|
Output resistance: |
50 W |
|
Proximitor Sensor Material: |
A380 aluminum |
|
Operating Temperature: |
-51°C to +100°C (-60°F to +212°F) |
|
Storage Temperature : |
-51°C to +105°C (-60°F to +221°F) |
|
Relative Humidity: |
100% condensing, non-submersible when connectors are protected. Tested to IEC 68-2-3 damp heat |
|
Proximitor Sensor Input: |
Accepts one noncontacting 3300 XL 25 mm Proximity Probe and Extension Cable. |
|
Power: |
Requires -17.5 Vdc to -26 Vdc without barriers at 12 mA maximum consumption, -23 Vdc to -26 Vdc with barriers. Operation at a more positive voltage than -23.5 Vdc can result in reduced linear range. |
|
Supply Sensitivity: |
Less than 2 mV change in output voltage per volt change in input voltage. |
|
Output resistance: |
50 W |
Competitive Advantage
Long-distance signal transmission
With 50 Ω output, the 330850-50-05 3300 XL 25 mm Proximitor Sensor transmits precise readings from turbine decks to control panels without amplifiers.
High-temperature operation near machinery
The 330850-50-05 3300 XL 25 mm Proximitor Sensor tolerates continuous +100°C and intermittent +105°C, allowing placement near thrust bearings or rotor assemblies.
Accurate output under DC variations
Less than 2 mV/V supply sensitivity ensures the 330850-50-05 3300 XL 25 mm Proximitor Sensor maintains 0.787 V/mm output during fluctuating DC power.
Humidity tolerance for turbine halls
Sealed connectors allow the 330850-50-05 3300 XL 25 mm Proximitor Sensor to operate in 100% condensing humidity without additional enclosures, enabling use in harsh process areas.
