330130-080-00-05 3300 XL Standard Extension Cable

Overview

Place of Origin:	USA
Brand Name:	Bently Nevada
Model Number:	330130-080-00-05
Minimum Order Quantity:	1
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Description

The 330130-080-00-05 3300 XL Standard Extension Cable is a critical component within the 3300 XL Proximity Transducer System, designed to extend the reach of 8 mm XL probes while maintaining precise signal integrity. This extension cable is engineered specifically for high-performance automation and industrial monitoring applications, including vibration analysis, position measurement, and speed sensing on fluid-film bearing machinery. By ensuring reliable signal transmission between the probe and Proximitor sensor, the 330130-080-00-05 cable supports accurate static (position) and dynamic (vibration) measurements, making it an indispensable part of predictive maintenance and machine health monitoring programs.

The 3300 XL Standard Extension Cable is fully compatible with the 3300 XL 8 mm proximity transducer probes and other 3300 series components, providing seamless interchangeability without the need for component-specific calibration. This backward compatibility allows integration with older non-XL 3300 series probes, including the 5 mm variants, offering flexibility for existing automation systems and facilitating upgrades in plant monitoring networks. The cable supports full compliance with API 670 standards, ensuring high linearity, temperature stability, and accuracy, which are essential for critical industrial operations in power generation, petrochemical processing, and heavy machinery monitoring.

Designed for durability in demanding industrial environments, the 330130-080-00-05 extension cable incorporates ruggedized insulation and a robust connector design, capable of withstanding mechanical stress and environmental exposure. The patented CableLoc design ensures that the cable maintains a secure connection to the probe, delivering a pull strength of up to 330 N (75 lbf) to prevent accidental disconnection during operation. For applications where fluid contamination is a concern, the optional FluidLoc feature further protects the system by preventing oil and other liquids from entering the cable assembly, enhancing both safety and longevity.

In automation setups, the 3300 XL Standard Extension Cable plays a vital role in transmitting precise proximity measurements over longer distances without signal degradation. It enables flexible installation in complex machine assemblies, including turbines, compressors, and pumps, where direct wiring between the probe and sensor is impractical. By maintaining high-fidelity signal transfer, this cable ensures that vibration and position data are reliably conveyed to monitoring systems, allowing real-time diagnostics, predictive maintenance, and operational optimization.

The 330130-080-00-05 3300 XL Standard Extension Cable exemplifies the advanced engineering behind the 3300 XL Proximity Transducer System. Its combination of robust construction, compatibility with multiple probe sizes, and adherence to industry standards makes it a cornerstone of industrial automation solutions, delivering both precision and reliability for machinery condition monitoring and predictive maintenance programs.

Applications

Vibration and Position Monitoring

The 330130-080-00-05 3300 XL Standard Extension Cable is designed to extend the 3300 XL 8 mm Proximity Transducer System for precise measurement of both static (position) and dynamic (vibration) values. When connected to 8 mm XL probes, this extension cable ensures high-fidelity signal transmission over distances up to 8 meters (26.2 feet), allowing accurate monitoring of machinery such as turbines, compressors, and fluid-film bearing equipment. By maintaining the integrity of the proximity signal, the cable supports predictive maintenance programs and real-time condition monitoring.

Integration with Keyphasor and Speed Measurement Systems

This extension cable enables reliable connection between XL probes and Proximitor sensors for applications requiring Keyphasor reference and rotational speed measurements. Its low capacitance of 69.9 pF/m (21.3 pF/ft) and stable output resistance of 50 Ω ensure minimal signal loss, supporting high-precision automation tasks in industrial environments. The cable’s compatibility with field wiring from 0.2 to 1.5 mm² (16 to 24 AWG) allows easy integration with existing monitoring systems.

Industrial Automation and Harsh Environment Use

The 3300 XL Standard Extension Cable is built for demanding industrial applications, with operating and storage temperatures ranging from -52°C to +177°C (-62°F to +350°F). Constructed with 75 Q triaxial fluoroethylene propylene (FEP) insulation, it resists chemical exposure, mechanical stress, and extreme temperatures, making it suitable for petrochemical, power generation, and manufacturing automation. Optional CSA, ATEX, and IECEx approvals ensure compliance with global safety standards, allowing safe deployment in hazardous areas.

Enhanced Reliability and Maintenance Efficiency

Designed with a patented CableLoc connection system, the 3300 XL extension cable provides a secure 330 N (75 lbf) pull strength attachment to the probe, minimizing the risk of accidental disconnection during operation. For applications with potential fluid exposure, the optional FluidLoc design prevents oil or liquid ingress, protecting the cable interior and ensuring consistent signal performance. Its backward compatibility with other 3300 XL and non-XL series probes facilitates easy upgrades and reduces the need for component-specific calibration, enhancing overall automation system efficiency.

Flexible Installation in Complex Machinery

The extended cable length option allows probes to be positioned optimally in tight or remote areas while maintaining accurate distance measurements. It supports linear ranges up to 2 mm (80 mils) with recommended gap settings for radial vibration at approximately 1.27 mm (50 mils), ensuring precise alignment and vibration detection across various rotating machinery setups.
